Study on the Optimal Design Methodology of Fracture Spacing in Low-Permeability Reservoir Horizontal Well

Abstract:

Threshold pressure gradient for extra-low permeability reservoir is studied experimentally. A production model is established which couples wellbore pipe flow, fracture linear flow and reservoir non-Darcy flow. The influence of bottom-hole pressure and reservoir permeability on threshold distance is performed based on the model. A fracture spacing design method is provided for different bottom-hole pressure and reservoir permeability. Results show that threshold pressure gradient increases considerably as permeability decreases when permeability is below 0.02 mD; threshold pressure gradient is relatively lower when permeability is greater than 0.1 mD; threshold pressure gradient decreases gradually and flattens when permeability lies between 0.02 mD and 0.1 mD. Simulated threshold pressure gradient of formation water is as one-third as that of crude oil. While permeability is between 0.01-0.05 mD, 0.05-0.1 mD, 0.1-0.5 mD and 0.5-1.0 mD, the optimal fracture spacing is about 9 m, 16 m; 36 m and 50 m.

• Periodical: Advanced Materials Research (Volume 868)
• Pages: 487-496
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.868.487
• Online since: December 2013
• Authors: Guo Cheng Zhang, Yang Liu, Zhao Hui Zhang
• Keywords: Fracture Spacing Optimization, Low-Permeability Reservoir, Non-Darcy Flow Coupled Model, Threshold Pressure Gradient

References

[1] Zhang Zhiqiang, Zheng Wei. Exploration and development technical progress of low permeability oil and gas [J]. Advances in Earth Science. 2009. 24 (8): 854-864. In Chinese.

[2] Hu Wenrui. Present and Future of low permeability oil and gas in China [J]. China Engineering Science. 2009. 11 (8): 29-36. In Chinese.

[3] Wen Qingzhi, Pu Chunsheng, Qu Zhanqing, etc. Low permeability, low permeability reservoir fracturing non-Darcy flow overall optimization design [J]. Petroleum Geology and Recovery . 2009. 16 (6): 102-107. In Chinese.

[4] Jian Hua. Low permeability reservoir percolation characteristics and reasonable spacing analysis [J]. Oil and Gas Technology 2005 (05) . 27 (5): 621-623. In Chinese.

[5] Zhu Chunsheng, Cheng Linsong, Yang Zhonghua, Chen Pu. Ultra-low permeability sandstone reservoir flow characteristics [J]. Petroleum Geology and Recovery. 2008. 15 (2): 102-104. In Chinese.

[6] Li Tao. China Oilfield Development Series: low permeability oilfield development [M]. Beijing: Petroleum Industry Press, 1997. In Chinese.

[7] Huang Yan Zhang. Low permeability reservoir percolation mechanism [M]. Beijing: Petroleum Industry Press, 1997. In Chinese.

[8] Feng Lizhong, He Shunli, doors sake of low permeability oilfield law of non-Darcy flow [J]. Wells tested. 2005. 14 (3): 14-17. In Chinese.

[9] Doris, Liu Min, Zhang Shaohui, Yao Jun of extra low permeability reservoir percolation characteristics experimental study [J]. Xi'an Shiyou University (Natural Science Edition). 2008. 23 (2): 35-39. In Chinese.

[10] Jiang Jinbao, Lin Yingsong, Ruanxin Fang, Ding Yansheng. Transformation of low permeability reservoir technology research and development [J]. Drilling & Production Technology. 2005. 28 (5) 50-53. In Chinese.

[11] B.W. McDaniel, R.M. Willett. Stimulation Techniques for Low-Permeability Reservoirs with Horizontal Completions that Do Not Have Cemented Casing [J]. 2002. SPE75688.

DOI: 10.2118/75688-ms

[12] Gao Haihong, Cheng Linsong, Qu Zhanqing. Fractured horizontal wells fracture parameter optimization [J]. Xi'an Shiyou University (Natural Science Edition). 2006. 21 (2): 29-32. In Chinese.

[13] Liang Tian, Sun Yijian, Huang Zhiwen, Xia Jiu, Li Zongtian of low permeability reservoir horizontal well fracturing optimization design [J]. Xi'an Shiyou University (Natural Science Edition) . 2009. 24 (3): 45-48. In Chinese.

[14] Hui Cengfan, Guo Jianchun, Xu Yan Bo, Zhao Jinzhou. Fractured horizontal well productivity influencing factors [J]. Petroleum Exploration and Development. 2007. 34 (4): 474-477. In Chinese.

[15] Qu Zhanqing, Zhao Yingjie, Wen Qingzhi. Horizontal well fracturing parameters optimization [J]. Petroleum Geology and Recovery. 2012. 19 (4): 106-110. In Chinese.

[16] Hao Fei. Extra low permeability reservoir linear flow characteristics of [D]. Beijing: China University of Petroleum (Beijing). 2007. In Chinese.

[17] Wang Zhiming, Jin Hui, Wei Jianguang. Fractured horizontal well fracture and reservoir inflow variable mass flow coupling model [J]. Hydrodynamics Research and Development Series A. 2009, 24 (2): 172-179. In Chinese.

[18] Wang Zhiming, Qi Zhenlin, Wei Jianguang, Jin Hui. Fracture parameters on fractured horizontal well inflow dynamics [J]. China Petroleum University (Natural Science Edition). 2010. 34 (1): 73-78. In Chinese.
