Delineation of Hydrocarbon with Variation of Overburden Thickness for Sea Bed Logging Applications

Abstract:

There are various methods being used to model and study behavior of electromagnetic (EM) waves in controlled source electromagnetic (CSEM) environment. Sea Bed logging (SBL) is using CSEM technique in detecting and characterizing hydrocarbon bearing reservoirs in deep water areas. It uses a mobile horizontal electric dipole (HED) source called transmitter that transmits low frequency of 0.1Hz to 10Hz, 30m - 40m above sea bed and an array of seafloor electric field receivers. These signals depend on the resistivity structure beneath the sea bed as hydrocarbon is known to have high resistivity value of 30 500 Ωm in contrast to sea water layer of 0.5 2 Ωm and sediments of 1-2 Ωm. Array of seafloor receivers detect EM energy that propagates through the sea and subsurface. Data collected is used for processing and modeling purposes to predict depth of resistive bodies. In this paper, synthetics data generated from developed simulator that is able to replicate SBL environment is compared to synthetics data generated from Computer Simulation Software (CST) and COMSOL software with same parameter setting to study trends between them. Percentage differences between data with hydrocarbon and without hydrocarbon are calculated and comparisons are made. Overburden thickness is varied from 1000m to 3000m (incremented by 500m) at frequency of 0.125Hz. It was found that all the data generated either from simulator, CST software and COMSOL showing the same trends. From these findings it shall conclude that the simulator is a reliable tool to model any sea bed logging environment and predicting present of hydrocarbon reservoir in SBL environment.

• Periodical: Advanced Materials Research (Volumes 875-877)
• Pages: 1069-1075
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.875-877.1069
• Online since: February 2014
• Authors: Hanita Daud, Sagayan Vijanth, Muizuddin Talib Ahmad
• Keywords: Controlled Source Electromagnetic, Forward Model, Plane Layer Model, Sea Bed Logging

References

[1] V. Loan, F. Charles: 1997, Introduction to Scientific Computing, New Jersey: Prentice Hall.

[2] E.N. Kong, H. Westerdhal: 2002. - May 13, Seabed Logging: A possible direct hydrocarbon for deepsea prospects using EM energy,. Oslo  : Oil & Gas Journal, 2002 edition.

[3] J. Park, T.I. Bjornara, H. Westerdahl, E. Gonzalez: 2008, On Boundary Conditions for CSEM Finite Element Modeling, Proceedings of COMSOL Conference, Hannover, Canada.

[4] F. Roth, F.A. Maao: 2007 Improving Seabed Logging Sensitivity in Shallow Water Through Up-Down Separation,  - Trondhiem, Norway : EGM 2007 International Workshop.

DOI: 10.3997/2214-4609-pdb.166.b_op_09

[5] A. Bhuiyan, T. Wicklund, S. Johansen: January 2006 High Resistivity Anomalies at Modgunn Arch in the Norwegian Sea, Technical Article, first break volume 24.

DOI: 10.3997/1365-2397.2006001

[6] D. Andreis, L. MacGregor: 2008 Controlled-source electromagnetic sounding in shallow water: Principles and applications, Geophysics, Vol 73, No1 (January – February 2008), F21 – F32.

DOI: 10.1190/1.2815721

[7] H. Daud, N. Yahya, V. Sagayan, K. Ihsan, 2010: Development of EM Waves Simulator for Sea Bed Logging Applications using MATLAB, 6th International Conference on Intelligent Unmanned Systems, by Institut Teknologi Bandung, in Bali Indonesia, 3rd Nov – 5th Nov, (2010).

DOI: 10.1109/apace.2010.5720092

[8] Available Online on http: /en. wikipedia. org/wiki/Computer_Simulation_Technology.

[9] Available Online on http: /en. wikipedia. org/wiki/COMSOL_Multiphysics.

[10] S.U. Evan, D.L. Alumbaugh: 2007, Marine CSEM Methods – on the Physics of the Marine CSEM Method, Geophys. Res. Vol. 72, No. 2, pp.13-18.

[11] E.S. Krebes: 2004 Seismic Forward Modeling,. University of Calgary, Calgary : CSEG RECORDER.
