The Effect of Cutting Process Parameters on the Stability in Milling

Abstract:

In the milling process, the dynamic system in the cutting process is composed of the tool, workpiece, and machine tools themselves. Therefore the mill geometric parameter, workpiece material behavior, and the modal parameters of the cutting system all will influence the stability in milling. Using FLN method and convolution force model to predict the chatter stability of milling process, and discussing the effect of milling parameter on the stability in this article. According to the result: with the increase of the tool diameter, stiffness, damping ratio or the reducing of tangential cutting force coefficient and radial width of cut, the stability lobe diagram tends to move upward. With the increase of natural frequency, the stability lobe diagram tends to move to right side. With the increase of the number of tooth, the stability lobe diagram tends to move downward.

• Periodical: Advanced Materials Research (Volumes 887-888)
• Pages: 1200-1204
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.887-888.1200
• Online since: February 2014
• Authors: Te Ching Hsiao*, Shyh Chour Huang
• Keywords: Chatter, Stability Lobe Diagram, Stiffness

References

[1] Tobias, S.A. and Fishwick, W., Theory of Regenerative Machine Tool Chatter, Engineering, Vol. 205, (1958).

[2] Merritt, H. E., Theory of Self-Excited Machine Tools Chatter, , Journal of Engineering for Industry, Vol. 87, pp.447-454, (1965).

DOI: 10.1115/1.3670861

[3] Tlusty, J., Ismail, F., Special Aspects of Chatter in Milling, Journal of Vibration, Stress, and Reliability in Design, Vol. 105, pp.24-32, (1983).

DOI: 10.1115/1.3269061

[4] Tlusty, J., Zaton,W., Ismail, F., Stability Lobes in Milling, Annals of th CIRP, Vol. 32, pp.309-313, (1983).

DOI: 10.1016/s0007-8506(07)63411-8

[5] Yuan, Zeh-jun and Cai, Li-jun, A New Critical Stability Formula and a New Absolute Stability Criterion, , Annals of CIRP, Vol. 35, pp.267-268 (1986).

DOI: 10.1016/s0007-8506(07)61885-x

[6] Minis, I., and Yanushevsky. R., A New Theoretical Approach for the Prediction of Machine Tool Chatter in Milling, Journal of Engineering for Industry, Trans. ASME , Vol. 115, pp.1-8, (1993).

DOI: 10.1115/1.2901633

[7] Altintas, Y. and Budak, E., Analytical Prediction of Stability Lobes in Milling, Annals of the CIRP, Vol. 44, pp.357-362, (1995).

DOI: 10.1016/s0007-8506(07)62342-7

[8] Insperger, T., and Stépán, G. , Semi-discretization method for delayed systems, International Journal for Numerical Methods in Engineering, 55, pp.503-518, (2002).

DOI: 10.1002/nme.505

[9] Wang, J. J., Zheng, C. M. and Huang, C.Y., The effect of harmonic force components on regenerative stability in end milling, ASME/IMECE, Washington, D.C. November 15-21, (2003).

[10] Merdol S. D., Altintas Y., Multi frequency solution of chatter stability limits for low immersion milling, , Journal of Manufacturing Science and Engineering, Transactions of the ASME, Vol. 126(3), pp.459-466, (2004).

DOI: 10.1115/1.1765139

[11] Ding Y., Zhu L. M, Zhang X.J., Ding H., A Full-discretizatipon method for prediction of milling stability, International Journal of Machine Tools and Manufacture, Vol. 50(5), pp.502-509, (2010).

DOI: 10.1016/j.ijmachtools.2010.01.003
