Dynamic Response of Thin-Walled Structures to Thermal Loadings and Random Acoustic Excitations

Abstract:

Hypersonic aircrafts are facing increasingly severe aerodynamic heating, noise and so on, which will lead to nonlinear vibration characteristics for thin-walled structures of hypersonic aircrafts. Considering the influence of thermo-acoustic loadings, finite element formulation of simply supported plate under combined thermo-acoustic loadings are founded, and vibration characteristics of simply supported plate under thermal loadings with temperature gradient and random acoustic loadings are investigated. According to finite element numerical method, modal frequencies, critical thermal buckling temperature difference, dynamic stress response of simply supported plates with temperature gradient under combined thermo-acoustic loadings were calculated before and after thermal buckling. The results show that three types of motion: random vibrations around initial equilibrium position in pre-buckling region, snap-through oscillations between two post-buckling equilibrium positions, nonlinear vibrations around one of the two post-buckling equilibrium position, and The RMS of nodes for different locations of the simply plate are obtained in pre-buckling post-buckling region, and it is shown that different interaction of tensile bend stress, compressive stress and compressive thermal stress lead to different RMS trends.

• Periodical: Advanced Materials Research (Volumes 889-890)
• Pages: 1398-1405
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.889-890.1398
• Online since: February 2014
• Authors: Feng Tong Zhao*, Yun Dong Sha, Xiao Chi Luan, Lin Zhu
• Keywords: Acoustic Excitations, Critical Thermal Buckling Temperature Difference, Dynamic Response, Temperature Gradient, Thin Walled Structure

References

[1] McEwan, M.I., Wright, J.R., Cooper, J.E., and Leung, A.Y.T. A Finite Element/Modal Technique for Nonlinear Plate and Stiffened Panel Response Prediction, AIAA-2001-1595, (2001).

DOI: 10.2514/6.2001-1595

[2] Ng, C. F. Journal of Aircraft, 26(3): 281-288(1989).

[3] Ko W L. Thermal Buckling Analysis of Rectangular Panels Subjected to Humped Temperature Profile Heating[R]. NASA/TP-2004-212041, (2004).

[4] Dhainaut, Jean-Michel, et al. Nonlinear random response of panels in an elevated thermal-acoustic environment., Journal of aircraft, 40. 4: 683-691(2003).

DOI: 10.2514/2.3146

[5] Mei, C. and Wolfe, H. F. On Large Deflection Analysis in Acoustic Fatigue Design. Random Vibration Status and Recent Developments, I. Elishakoff and R. H. Lyon (ed. ), Elsevier, Amsterdam, pp.279-302(1986).

DOI: 10.1016/b978-0-444-42665-9.50023-2

[6] Mei, C. and Prasad, C. B. Proceedings of the AIAA/ASME/ASCE/AHS 28th Structures, Structural Dynamics, and Materials Conference, AIAA, New York, pp.809-826(1987).

DOI: 10.2514/msdm09

[7] Holehouse, I. Sonic Fatigue Design Techniques for Advanced Composite Aircraft Structures., Air Force Wright Aeronautical Lab-oratories, Wright-Patterson AFB Ohio, TR-80-3019, (1980).

[8] Ng, C. F. and White, R. G. The Dynamic Behavior of Postbuckled Composite Plates Under Acoustic Excitation., Composite Structures, Vol. 9, Jan, pp.19-35(1988).

DOI: 10.1016/0263-8223(88)90029-3

[9] Sha Y D, Gao Z J, Xu F. Applied Mechanics and Materials, 105: 220-226(2012).

[10] Sha Y D, Gao Z J, Xu F, et al. Influence of thermal loading on the dynamic response of thin-walled structure under thermo-acoustic loading[C]/Advanced Engineering Forum. 2: 876-881(2011).

DOI: 10.4028/www.scientific.net/aef.2-3.876

[11] Sha Y D, Wei J, Gao Z J, et al. Journal of Vibration and Control accepted (2012).

[12] Yundong Sha, Jiyong Li, and Zhijun Gao. Applied Mechanics and Materials 80: 536-541(2011).

[13] Xue D Y, Mei C. AIAA journal, 31(1): 154-162(1993).

[14] Xinyun Guo, Adam Przekop and Chuh Mei. Structural Dynamics & Materials Conference, 19-22(2004).

[15] Sha Y D, Xu F, Gao Z J. Applied Mechanics and Materials, 117: 876-881(2012).

[16] Yang S M, Tao W Q[M]. Heat transfer. 4th Edition. Beijing: Higher Education Press(2006). In Chinese.

[17] Javaheri R, Eslami M R. AIAA Journal, 40: 162-169(2002).
