Study on the Flange Spread of H-Beam

Abstract:

According to the production data of a rolling H-beam factory, the FE model of hot continuous rolling process of H-beam is built. The rolling process of H-beams is simulated by explicit dynamic FEM, and the influence of deformation parameters on the spread of rolling piece is analyzed. The simulation results show that the flange width, elongation ratio between flange and web and flange thickness are the major influencing factors on the spread of rolling piece.

• Periodical: Advanced Materials Research (Volume 898)
• Pages: 213-216
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.898.213
• Online since: February 2014
• Authors: Jin Hong Ma*, Xiao Han Yao, Bin Tao
• Keywords: Finite Element Method (FEM), H-Beam, Numerical Simulation, Spread

References

[1] Z.H. He: Anhui construction. 2000, (1): 98-101(in Chinese).

[2] W. P Sun: METALLURGICAL TRANSCTIONS A. Vol. 23A, Nov (1992).

[3] Q.Q. He, Q.H. Zhang, H.L. Zhang, et. al: Forging &Stamping Technology. 2009, 34(3): 88-91.

[4] Q.Q. He, J. Sun , B.M. Yuan , et. al: Journal of South China Universtity of Technology (Natural Science Edition), 2010, 38(1): 144-148.

[5] G.T. Ma, Y. Zang : Journal of University of Science and Technology Beijing, 2008(2): 165-168.

[6] J.Z. Bai: Theoretical foundation and Case Analysis of LS-DYNA3D, Peking: science press, 2005: 93-115.
