On Multiple Model Adaptive Control Strategy Research of Ball and Plate System

Abstract:

The ball and plate system is a multi-variable and strongly nonlinear-controlled object of which is a system of two-dimensional extension with the variables amid having strong coupling function, and simultaneously it demands the closed loop control system owning good transient process and transient response. From perspective of international and domestic scale, ball and plate system has not figured out effective-control scheme. Take into account the ball and plate system possesses trait of nonlinearity and high requirements for transient response, etc. This paper proposes multiple model adaptive control strategy which is very suitable for such system, as well as the direction and guidance of such research.

• Periodical: Advanced Materials Research (Volume 898)
• Pages: 501-505
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.898.501
• Online since: February 2014
• Authors: Bao Yong Zhao*, Xiao Li Li
• Keywords: Ball System Multiple Model Adaptive, Plate System Multiple Model Adaptive

References

[1] HUMU SOFT L td, Use's manual for CE1512Ball & P late Apparatus, (1993).

[2] Googol Technology, user manual and experimental instruction of ball and plate system GPB2001, V1. 13 (2009).

[3] Narendra K. S., Balakrishnan J., Ciliz M. K. Adaptation and learning using multiple models, switching and tuning . IEEE Control Systems Magazine, 1995, 15 (1): 37-51.

DOI: 10.1109/37.387616

[4] Yu C., Roy R.J., Kaufman H. and Bequette B.W. Multiple-model adaptive predictive control of mean arterial pressure and cardiac output. IEEE Transactions on Biomedical Engineering, Aug, 1992, 39: 765-778.

DOI: 10.1109/10.148385

[5] Banerjee A., Arkum Y., Ogunnaike B. and Pearson R. Estimation of nonlinear using linear multiple models . AICHE Journal Chemical Engineering Research and Development, 1997, 43(5): 1204-1225.

DOI: 10.1002/aic.690430511

[6] Hauser J, Sastry S, Kokotovic P. Nonlinear control via approximate input output linearization: the ball and beam example. IEEE Transactions on Automatic Control, 1992, 37 (3) : 392-398.

DOI: 10.1109/9.119645

[7] Li Jun, Sun Zhengshun. Fuzzy control in simulation research of ball and plate system, journal of electrical machine and control, 2001, 5(4): 270-273. In Chinese.

[8] Wang Geng, Sun Zhengshun. PD fuzzy control algorithm research of ball and plate control system, electrical transmission 2004, (4) : 23-25. In Chinese.

[9] Teng Shujie, Zhang Nairao , Fan Xingzhe. T-S fuzzy multi-variable control scheme of ball and plate system, 2002, 31(3): 268-271. In Chinese.

[10] Li Denghui, Zhao Shimin, Sun Zhengshu. Fuzzy neural network control of ball and plate system, 2006, 6(5): 540-543. In Chinese.

[11] Su Xin, Sun Zhengshun, Zhao Shimin. Fuzzy control method research of ball and plate system, 2006, 23(9): 165-167. In Chinese.

[12] Chen Lingji, Narendra K. S. Intelligent control using multiple neural networks. Int. J. Adapt. Control Signal Process. 2003, 17(6): 417-430.

DOI: 10.1002/acs.759
