The Design of Shafting Condition Monitoring System for Rotating Machinery Based on Fiber Bragg Grating Sensor

Abstract:

FBG (Fiber Bragg Grating) is especially suitable for the shafting operation condition monitoring of rotating machinery under the harsh working environment for a long time with its advantages of anti-electromagnetic interference, easy reuse, good stability, environmental adaptability and so on. The overall architecture of the shafting operation condition monitoring system based on FBG sensing network is proposed. In the system, FBG multi-channel distributed sensing network is used to fully apperceive the real-time operation condition information of the equipment. While the Windows Presentation Foundation (WPF) and 3-Dimensional Studio Max (3DMAX) technologies are used to realize the intuitive 3-Dimensional (3D) virtual display to monitor the equipment. Besides, the sensing information data stream is processed in real time to display the running state of the equipment. Also, mass sensing information is analyzed and stored by the real-time processing method. The stability and reliability of the proposed framework and key technology is verified by the system long-time implementation results.

• Periodical: Advanced Materials Research (Volume 898)
• Pages: 738-742
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.898.738
• Online since: February 2014
• Authors: Fan Qiu*, Quan Liu, Jing Song Li, Fan Zhang
• Keywords: 3-Dimensional Virtual Display, Fiber Bragg Grating, Real-Time Operation Condition Monitoring, Stream Processing

References

[1] Min Xu, Shuyun Jiang, Ying Cai: An improved thermal model for machine tool bearings [J]. International Journal of Machine Tools and Manufacture. 47 (2007): 53-62.

DOI: 10.1016/j.ijmachtools.2006.02.018

[2] Chuliang Wei, Zemin Cai: Real-time fault diagnosis of train bogie using FBG sensors [C]/ 2012 International Conference on Intelligent Systems Design and Engineering Applications. (2012), 1087-1090.

DOI: 10.1109/isdea.2012.433

[3] Desheng Jiang, Kajia Che, Ciming Zhou, Jun Huang, Dian Fan: Research and application of fiber Bragg grating safety monitoring method for huge structures and equipments [J]. Proc. SPIE 7677. Fiber Optic Sensors and Applications VII, 76770K (2010).

DOI: 10.1117/12.851151

[4] Ecke. Wolfgang, Schmitt. Matthias W., Shieh. Yang, Lindner. Eric; Willsch. Reinhardt: Continuous pressure and temperature monitoring in fast rotating paper machine rolls using optical FBG sensor technology. Proceedings of SPIE - The International Society for Optical Engineering. 8421 (2012).

DOI: 10.1117/12.970314

[5] Zude Zhou, Quan Liu, QingSong Ai, Cheng Xu: Intelligent monitoring and diagnosis for modern mechanical equipment based on the integration of embedded technology and FBGS technology [J]. Measurement. (2011), 44 (9): 1499-1511.

DOI: 10.1016/j.measurement.2011.05.018

[6] Xiyuan Chen, Fang Lin: Performance analysis and experimental verification for FBG sensors applied for smart structure [J]. Key Engineering Materials, 2 (2007): 1357-1360.

[7] Jun Liu, Desheng Jiang: Study of Data Acquisition for Bridge Health Monitoring System Base on Fiber Grating Sensing　Technology [J]. Microcomputer information Control and Automation Publication Group. (2009), 25 (6): 156-158.

[8] Yu Ren, Lu Gubing, Lu Feng: A method of rotation transformation for 3D object by changing camera attributes in WPF [C]/ 2010 2nd International Conference on Information Engineering and Computer Science. Piscataway: IEEE Computer Society, (2010).

DOI: 10.1109/iciecs.2010.5678267
