Analysis on Strength of Dropping System Based on Dynamics and Statics

Abstract:

Shipborne dropping system is used widely in national defense and ocean engineer. Dropping system is moving with ship in voyage, so it's difficult to analyze precisely the strength of dropping system resulting from the complex dynamics. To solve the problem, firstly based on ADAMS software, in the paper the dynamic model is created and analyzed, and maximum load of every part of dropping system is achieved one by one. Then, static analysis of every part is researched to checkout structural strength based on ANSYS software platform, and improving part structure with weak point. In the paper the method and research make sure that the dropping system is safety and available.

• Periodical: Advanced Materials Research (Volume 902)
• Pages: 179-184
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.902.179
• Online since: February 2014
• Authors: Xing Man Yang*, Zhi Zhou, Gang Xi
• Keywords: Dropping System, Dynamic, Statics, Strength

References

[1] Ru Chengyao: Modern torpedo and mine technology research, Ship Science and Technology Vol. 25(2003), pp.42-47.

[2] LIU Zheng-yuan, WA NG Lei and CUI Wei-cheng: State-of-the-art development of the foreign unmanned submersibles, Journal of Ship Mechanics Vol. 15(2011), pp.1182-1193.

[3] FANG Shu-jia: Marine environment monitoring: essential to marine development and rights guarding, Ship Science and Technology Vol. 34(2012), pp.4-10.

[4] Information on http: /www. mscsoftware. com/product/Adams.

[5] WANG Xiu-shan, YANG Jian-guo and WU Hao: Building research on virtual prototype of gear speed reducer based on Pro/E, ADAMS and ANSYS, Journal of Shanghai Jiaotong University Vol. 41(2007), pp.1-4.
