A Guiding Robot for Minimally Invasive Spinal Surgery Based on Parallel Manipulator

Abstract:

Nowadays, surgical robot has been the research hot spot of the interdisciplinary which includes medical science and robotics field. Surgical robot not only can complete complicated and repetitive work in the radiation and other environment as the substitute of doctor, but also expand doctors capacity of perception and operation, enhancing the operation precision and safety. This paper is based on a three freedom parallel manipulator and considers the characteristics of minimally invasive spinal surgery to design a guiding robot. In this article , the theoretical analysis about kinematics and dynamics is done and the analytic equation is established. The solution to the equation is derived by MATLAB toolboxes. The physical prototype is made based on the solution, the properties of physical prototype are measured and the feasibility of the design is verified.

• Periodical: Advanced Materials Research (Volume 902)
• Pages: 280-285
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.902.280
• Online since: February 2014
• Authors: Cai Ru Meng, Nan Wang, Qiang Li, Xian An Li, Qing Yang Liu, Peng Gao
• Keywords: Guiding Robot, Minimally Invasive Spinal Surgery, Parallel Manipulator

References

[1] J. D. hernandez, S. D. bann, Y. Munz, et al. Qualitative and quantitative analysis of the learning curve of a simulated surgical task on the da Vinci system[J]. Surg Endosc (2004) 18: 372~378.

DOI: 10.1007/s00464-003-9047-3

[2] Ranjit Rao, Rishi nayyar, S. Panda, et al. Surgical techniques: robotic bladder diverticulectomy with the da Vinci-S surgical system[J]. J Robotic Surg(2007) 1: 217~220.

DOI: 10.1007/s11701-007-0030-1

[3] Jingjun Yu, Xinjun Liu, Xilun Ding, et al. Mathematical foundation of robot mechanism [M]. China Machine Press，2008. 11~12.

[4] Tsai, Ting-Nung Shiau, Yi-Jeng Tsai, et al. Direct kinematic analysis of 3-PRS parallel mechanism. Mechanism and Machine Theory. Volume38, Issue 1, January 2003: 71~83.

DOI: 10.1016/s0094-114x(02)00069-1

[5] F. Karstens, A. Stifoutkin , J. Tandle. Performance Tests of the ZEUS Straw-Tube Tracker. Nuclear Science Symposium Conference Record, 2005 IEEE: 1122~1126.

DOI: 10.1109/nssmic.2005.1596448

[6] M. Biabani, M. A. Golkar, A. sajadi. Operation of a Multi-Agent System for Load management in smart power distribution system. Environment and Electrical Engineering (EEEIC), 2012 11th: 525~530.

DOI: 10.1109/eeeic.2012.6221433

[7] Loi-Wah Sum, Feederick Van Meer, Yan Bailly, et al. Design and Development of a Da Vinci Surgical System Simulator. Mechatronics and Automation, 2007. ICMA 2007: 1050~1055.

DOI: 10.1109/icma.2007.4303693

[8] Ying Hu, Jianwei Zhang, Yi Chen, Junfeng Yao. Type Synthesis and Kinematic Anaylysis for a Class of Mobile Parallel Robots. Proceedings of the 2009 IEEE International Conference on Mechatronics and Automation August 9-12, Changchun, China: 3619~3624.

DOI: 10.1109/icma.2009.5246019
