Research on the Coordination Control between STATCOM and VQC in Substation Based on the Identification of System State

Abstract:

For traditional voltage and reactive power control (VQC) of substation will cause frequent adjustment of transformer taps and switching of capacitor banks, which exerts a certain impact on system voltage, the static synchronous compensator (STATCOM) is supposed to be installed in the substation to improve the effect of VQC. A coordination control strategy between STATCOM and VQC in substation based on the identification of system state is proposed in this paper to coordinate the operation between on-load tap changers (OLTC), capacitors and STATCOM. In addition, we have a research on the application effect of this strategy with BPA. The simulation results show that STATCOM plays an important role in improving the substation performance in both steady state and transient state and it can effectively reduce the frequency of tap changing and capacitor switching. Besides, the system will perform better if both of the main transformers are equipped with STATCOM than only one is configured.

• Periodical: Advanced Materials Research (Volume 905)
• Pages: 469-475
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.905.469
• Online since: April 2014
• Authors: Jian Hui Li, Jia Xin Zou
• Keywords: BPA, STATCOM, Steady Simulation, Transient Simulation, Vqc

References

[1] Zhuang Kanqin and Li Xingyuan. Strategies and Implementation Modes of Voltage and Reactive Power Control for Substations [J]. Power System Automation, 2001, 25(15): 47-50.

[2] Wei Xiaoyu and Yang Honggen. A New Strategy for Area Voltage/VAR Control Based on Operation State Diagnosing Method [J]. Power System Protection and Control, 2009, 37(24): 46-50.

[3] Cai Kai. New Discussion on Synthetically Control of Voltage and Reactive Power from Nine-zone Theory to Five-zone Theory [J]. Power System Automation, 2004, 28(19): 92-95.

[4] Lu Jizhi. Significance and Application of STATCOM in Substation [J]. Yunnan Electric Power, 2011, (8): 37 -38.

[5] Cui Xinqi and Zhu Ying. Characteristics and Control System of STATCOM [J]. Shanghai Electric Power, 2006, (5): 511-514.

[6] Rong Fang. Technology and Control Strategy of Dynamic Reactive Power Compensation for Distribution Network [J]. The World of Inverters, 2009, (6): 102-105.

[7] Liu Xiao, Chen Xiaoning, Gao Cheng, et al. Application and Development of Static Synchronous Compensator (STATCOM) [J]. Science and Technology Innovation Herald, 2008, (15): 4-6.

[8] DU Sheng, Zhang Pengyuan and Fang Gang. SVG Technology Review [J]. China New Technologies and Products, 2009, (17): 5.

[9] Cai Wei and Zhang Jian. Research on Application of STATCOM to Improve the Voltage Stability of the Power System [J]. Enterprise Science and Technology & Development, 2007, (14): 87-88.

[10] Liu Lixia, Yi Shuwei and Yao Yanmin. Functions of SVC and STATCOM for voltage stability [J]. East China Electric Power, 2006, 8 (34): 14-16.

[11] Wang Haifeng, Li Haifeng and Chen Heng. Power System Voltage Control Based on Learning Humeral Immune Response [J]. Proceedings of the CSEE, 2003, 23(2): 31-36.

[12] S. Mishra and B.K. Panigrahi. A Hybrid Adaptive Bacterial Foraging and Feedback Linearization Scheme Based D-STATCOM [C]. 2004 International Conference on Power System Technology, Singapore, 2004: 275-280.

DOI: 10.1109/icpst.2004.1460006

[13] Duan Wenli, Bai Yanli and Wei Fei. Coordination Control of OLTC Transformers, Capacitor Banks and STATCOM [J]. Advances of Power System & Hydroelectric Engineering, 2012, 28 (1): 54-59.

[14] Zhao Wei, Luo An, Tang Jie, et al. Hybrid Var Compensator Based on the Coordinated Operation of STATCOM and TSC [J]. Proceedings of the CSEE, 2009, 29 (19) 92-97.

[15] Liu Guangye, Shi Hailiang and Yang Yihan. Comprehensive Dynamic Analysis Method for Power System Static Voltage Stability [J]. Proceedings of the CSEE, 2013, 4 (12): 36-42.
