660MW Single Auxiliary Ultra-Supercritical Unit Main Stream’s Temperature Control Strategy Optimization Studies

Abstract:

2 × 660MW ultra-supercritical units of O'Brien Power Plant are single configuration of auxiliary pilot project, due to the higher its parameters and performance requirements, it need better control strategies to ensure safe and economical operation. Against traditional cascade PID main steam’s temperature control system delaying large, this article proposed control strategy based on Smith estimated. Main steam’s temperature controlled object inert zone mathematical model can be showed by multi-volume model, and use the improved system for large inertia Smith Predictor to make dynamic parameter control systems improvements. Simulation results of the simulation machine show that: Optimization emperor steam temperature control is in an adjustable range and the policy in separate auxiliary units is feasible.

• Periodical: Advanced Materials Research (Volume 909)
• Pages: 317-322
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.909.317
• Online since: March 2014
• Authors: Huan Pao Huang, Ji An Yu, Qian Su, Lei Wang
• Keywords: Main Steam’s Temperature Control Strategy, Optimization, Single Auxiliary, Smith Estimates, Ultra-Supercritical

References

[1] Meng Guo, Xudong Li, Huabing Ning , etc. Configuration of Single-Row Fan in 660 MW Ultra-Supercritical Unit[J]. Electric Power Construction, 2013, 34(10): 76-80.

[2] Jie Bai, Dongwen Peng, Dahong Zhu. Discussion on Single Set of 300 MW Flue-Gas System[J]. Electric Power Construction, 2010 (009): 87-90.

[3] Afeng WU, Canshen TAN. Technical and Economical Analysis on Single- and Dual-train Fan Configuration in Thermal Power Plants[J]. Power Equipment, 2012, 26(2): 88-92.

[4] Jia Luo, Feng LI, Hongfu Zhang, Yaqing Zhu. Gain Adaptive Smith Prediction Control of Superheated Steam Temperature[J]. Proceedings of The Chinese Society of Universities, 2010, 22(1): 156-160.

[5] Genjie Chen, Henghua Wei, Meisheng Xue. Design of Predictive PID Controller with Smith Predictor[J]. Electronic Technology, 2009, 8: 004.

[6] Wenjun Wang, Su Song, Xianxian Guo. Overview of Neural Network Adaptive Control[J] . The computer simulation. 2005, 8: 036.

[7] Changliang Liu, Fei Ming. Control Strategy Simulation of Main Steam Temperature Control for 1GW Ultra-supercritical Power Unit [J]. Control and Instruments in Chemical Industry, 2011, 9: 005.

[8] Fei Yuan. Parameter Sensitivity of Smith predictor [J]. Process Automation Instrumentation, 1988, 9(10): 13-18.
