The Detection Method of Black Field Failure and Static Frame Failure in Radio and Television Broadcast

Abstract:

Black field failure and static frame failure are two kinds of abnormal states in the process of radio and television broadcast. To explore an effective method to eliminate the two faults, so as to ensure the safety of radio and television broadcasting, has a very important practical significance. This paper introduces a method to detect black field failure and static frame failure which based on digital image processing techniques. During the detection,the image block processing is introduced, and the gray values of the inner frame images and the adjacent frame images need to be calculated and contrasted. The Matlab simulation analysis was carried on has proved its feasibility at last.

• Periodical: Advanced Materials Research (Volumes 912-914)
• Pages: 1456-1460
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.912-914.1456
• Online since: April 2014
• Authors: Xiao Lei Dong, Pei Tian, Zi Zhe Wang
• Keywords: Black Field Failure, Gray Value Contrast, Image Block, Inner Frame Image, Radio, Static Frame Failure, Television

References

[1] Ying Wang，Preliminary Evaluation of Radio and Television Broadcast Safety. Radio & Television Information [J], 2009: 104.

[2] Feng Zhou, Jiaolong Wei, The Detection of Black field and static frame in Television Signal[J]. The Cable Television Technology, 2005, 184(16): 89-91.

[3] Wenli Si, Research on the Digital Image Recognition Technology in Video Monitoring Applications [D], Beijing: University of Science and Technology Beijing, 2007: 30-34.

[4] Zuyu Sun, Design and Implementation of Detecting the Black Field and Static Frame [J]. Advanced Television Engineering, 2010 (012): 122-123.

[5] Chao Gou, Kunfeng Wang, Bin Hu, et al. A Fast Recognition Algorithm for Detecting Common Broadcasting Faults [J]. 2013 International Conference on. IEEE, 2013: 525.

DOI: 10.1109/soli.2013.6611470
