Function Analysis of Mature Products Based-on the Function Unit

Abstract:

The function hierarchy matrix and function incidence matrix was defined to describe the function and to achieve the function decomposing of mature products. At the same time, the function unit table was built, and then the function units of a kind of products were achieved based-on the table. The relationship between function units achieved above was expressed by using the function hierarchy matrix and function incidence matrix. The function incidence matrix was operated to get the function tree and function decomposing based on bottom-up method by using λ-intercept, a conception in fuzzy design.

• Periodical: Advanced Materials Research (Volumes 912-914)
• Pages: 1633-1636
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.912-914.1633
• Online since: April 2014
• Authors: Ming Hai Yuan*, Zhi Yong Dai, Shuo Cheng, Aai Min Ji
• Keywords: Function Decomposing, Function Hierarchy Matrix, Function Incidence Matrix, Function Unit Table

References

[1] SUN N P. Design Axioms and Quality Control [M]. Robotics and Computer Integrated Manufacturing, (1992).

[2] HOU Liang. The theory, method and practice application of modular design for mechanical product [D]. Hangzhou: Zhejiang University. 2003 (in Chinese).

[3] JIANG Hui, XU Yanshen, XIE Yan. Research on Modular Design for Mechanical Product [J] Manufacturing Technology & Machine Tool . 1999, (3): 7-9 (in Chinese).

[4] HUANG Hongzhong. Fuzzy design[M]. Beijing: Mechanical Industry Press. 1999(in Chinese).
