Research on the Arc-Teeth Synchronous Belt's Tooth Load Distribution Caused by the Machining Error

Abstract:

This paper aimed at the machining error of the arc-teeth synchronous belts tooth ,the 3D model was established with CATIA ,the finite element model of belt was established by HYPERMESH ,and using the multibody dynamic software RECURDYN, the models with different machining errors were simulated by rigid-flexible coupling technology. Systematically studied the changing rule of the wedged stress and the contact stress under the influence of the machining error. So it has certain value to enhance the loading capacity, transmission performance and useful life.

• Periodical: Advanced Materials Research (Volumes 915-916)
• Pages: 248-251
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.915-916.248
• Online since: April 2014
• Authors: Yao Chen Shi, Zhan Guo Li, Hao Li
• Keywords: Arc-Teeth Synchronous Belt, Load Distribution, Rigid-Flexible Coupling Technology

References

[1] Li Zhan-guo, Shi Yao-chen and Qin Shuan. Dynamics Analysis Research on Automotive straight tooth Synchronous Belt based on MFBD[J]. mechanical transmission, 2012, 36（9）：25-27.

[2] Li Zhan-guo, Shi Yao-chen, Qin Shu-an. Dynamics Stimulation Analysis Research on Automotive Multi-Wedge Synchronous Belt based on MFBD[J]. mechanical transmission, 2013, 37 (8)：34-37.

[3] Jiang Ming. Capability Research on Automotive Synchronous Belt. Chang-chun University of Science and Technology, (2008).

[4] JB/T 7512. 1-94 Arc-teeth Synchronous Belt.
