Dynamics Analysis of Vertical Transferring Frame of Garbage Container

Abstract:

In order to decrease the maintain cost and simplify the operation process of the frame of garbage transferring vehicle, a new scheme of vertical transferring frame of garbage container is provided, and the unloading process of the frame is given. The prototype model of the vehicle frame in unloading process is built. The simulated curve of the displacement of the lifting hydraulic cylinder and the turning angle of frame is accord with the theoretical computed one. By running the dynamic model, the dynamic curve of the force of the lifting hydraulic cylinder, the force of the sliding hydraulic cylinder, the force of the lug on sliding frame acted to container and the force of ground acted to container are obtained, which provide basis on designing the structure of the frame.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 915-916)

Pages:

39-44

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.915-916.39

Citation:

Cite this paper

Online since:

April 2014

Authors:

Li Wu*, Jia Yuan Zhang, Tian Min Guan, Lei Lei

Keywords:

Dynamic, Frame, Garbage Container, Transferring Vehicle, Vertical
