3D Simulation of Heavy-Ion Induced Charge Collection in Sub-100nm MOS-FETs Using Strained Silicon-Germanium

Abstract:

Single event transient of a PMOS using strained Silicon-Germanium in a sub-100nm bulk process is studied by 3D TCAD simulation. The impact of bias voltage, temperature, LET, and struck position on SET is considered. Our simulation results demonstrate that bias voltage in the range 0.8 to 1.2V greatly influence the amplitude of SET current. Temperature has a stronger influence on a SiGe channel PMOS than a Si-channel PMOS. Both SET current duration and total collection charge increase as LET increases, and SET current duration and total collection of a SiGe channel PMOS are larger than that of Si channel PMOS. These simulation results are beneficial to the space application of SiGe circuits.

• Periodical: Advanced Materials Research (Volume 918)
• Pages: 237-242
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.918.237
• Online since: April 2014
• Authors: Bin Zhou*, Xin Chun Wu, Ming Xue Huo
• Keywords: 3D Simulation, Charge Collection, Single Event Effect (SEE), Single Event Transient (SET)

References

[1] Y. -C. Yeo, Q. Lu, T. -J. King, et al. Enhanced Performance in Sub-100 nm CMOSFETs using Strained Epitaxial Silicon-Germanium. in International Electron Devices Meeting. pp.753-756 (2000).

DOI: 10.1109/iedm.2000.904427

[2] S. Sen, S. Chattopadhyay. Study of substrate induced strained-Si/SiGe channel for optimizing CMOS digital circuit characteristics. in International Conference on Computers and Devices for Communication (CODEC). pp.1-4(2012).

DOI: 10.1109/codec.2012.6509274

[3] C. Wei, T. Zhaohuan, T. Kaizhou, et al. A stained Si-channel NMOSFET with low field mobility enhancement of about 140% using a SiGe virtual substrate. Journal of Semiconductor. vol. 33, no. 9, pp.094005-4 (2012).

DOI: 10.1088/1674-4926/33/9/094005

[4] T. Ghani, M. Armstrong, C. Auth, et al. A 90nm High Volume Manufacturing Logic Technology Featuring Novel 45nm Gate Length Strained Silicon CMOS Transistors in IEEE International Electron Devices Meeting. p.11. 6. 1-11. 6. 3(2003).

DOI: 10.1109/iedm.2003.1269442

[5] J. Franco, B. Kaczer, M. Cho, et al. Improvements of NBTI Reliability in SiGe p-FETs in 2010 IEEE International Reliability Physics Symposium (IRPS). pp.1082-1085(2010).

DOI: 10.1109/irps.2010.5488668

[6] C. W. Leitz, M. T. Currie, M. L. Lee, et al. Hole mobility enhancements in strained Si/Si1-yGey p-type metal-oxide-semiconductor field-effect transistors grown on relaxed Si1-xGex (x<y) virtual substrates Applied Physics Letters. vol. 79, no. 25, pp.4246-4248(2001).

DOI: 10.1063/1.1423774

[7] M. L. Lee, E. A. Fitzgerald. Optimized strained Si/strained Ge dual-channel heterostructures for high mobility P- and N-MOSFETs in IEEE International Electron Devices Meeting. p.18. 1. 1-18. 1. 4(2003).

DOI: 10.1109/iedm.2003.1269314
