Research on Reinforcing Methods of Continuous Steel-Concrete Composite Beams with Web Openings

Abstract:

By considering the four secondary moment functions ,which are developed according to virtual plastic stress distribution at the perforated section of continuous composite beam. reinforced opening proved to be necessary and reliable .Several reinforcing methods are reserched. mechanical properties are compared with FE results in different reinforced continuous composite beam.The result indicates that the bending and vertical shear capacity of continuous composite beam with web opening can be effectively enhanced to a certain extent. In addition,stiffness and local stability at web opening area are also increase. Effective reinforcing method is presented and can be used in engineering practice.

• Periodical: Advanced Materials Research (Volumes 919-921)
• Pages: 1952-1957
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.919-921.1952
• Online since: April 2014
• Authors: Long Qi Li, Dong Hua Zhou, Wen Yuan Liao
• Keywords: Continuous Composite Beam, Fe, Reinforcing Methods, Web Opening

References

[1] Nie Jianguo, Yu Zhiwu. Research and practice of composite steel-concrete beams in China. China Civil Engineering Journal, 1999, 32(2): 3-8. (in Chinese).

[2] Nie Jianguo, Wu Hong, Zhou Jianjun, et al. Experimental study and rigidity analysis on composite steel-concrete beams with openings in concrete flange. China Civil Engineering Journal, 2006, 39(2): 31-35. (in Chinese).

DOI: 10.1016/j.engstruct.2005.11.004

[3] Nie Jianguo, Xiao Yan, Chen Lin. Experimental studies on shear strength of steel-concrete composite beams. Journal of Structure Engineering, ASCE, 2004, 130(8): 1206 – 1213.

DOI: 10.1061/(asce)0733-9445(2004)130:8(1206)

[4] Nie Jianguo, Chen Lin, Xiao Yan. Plastic analysis of shear behavior of composite steel-concrete beams. Engineering Mechanics, 2002, 19(5): 48-51. (in Chinese).

[5] Nie Jianguo, Chen Lin, Xiao Yan. Composite shear behavior of steel-concrete composite beams under sagging moment. Journal of Tsinghua University, 2002, 42(6): 835-838. (in Chinese).

[6] Clawson William C, Darwin David. Tests of Composite beams with web openings. Journal of Structure Engineering, ASCE, 1982, 108(3): 145 – 162.

DOI: 10.1061/jsdeag.0005856

[7] Donghua Zhou, Longqi Li, Jürgen Schnell, et al. Elastic Ddflections of Simply Supported Steel I-Beams with a Web Opening. Procedia Engineering, 2012. 31: 315-323.

DOI: 10.1016/j.proeng.2012.01.1030

[8] ZHOU Donghua, ZHAO Hui min, WANG Mingfeng, et al. Nonlinear calculation of a tested composite beam with web opening. Building Science Research of SiChuan , 2004, 30(2): 21 – 24.

[9] WANG Peng , ZHOU Donghua, WANG Yonghui, Nonlinear FEM Analysis on Steel-Concrete Composite Beam with Web Opening. Journal of Shenyang Jianzhu University ( Natural Science) , 2011, 27(5): 809 – 817.

[10] Zhou Donghua. Beitrag zum Tragverhalten und zur Entwicklung der Rechenmodelle von Verbundträgern mit Stegöffnungen. Universität Kaiserslautern, 1998 (in Germany).

DOI: 10.1002/stab.200002680

[11] Zhou Donghua. Auswirkung der Verformbarkeit der Verbundmittel und Teilverbundes auf das Tragverhalten und die Tragfähigkeit von Verbundträgern mit Quersch- nittssprüngen. Shaker-Press2003 (in Germany).

[12] Technical specification for steel structure of tall buildings(JGJ99-98). Beijing: China Architecture & Building Press, (1998).

[13] Wang Peng, Zhou Donghua, Wang Yonghui, et al. Experimental study on shear strength of steel-concrete composite beams with web opening. Engineering Mechanics, 2013, 30(3): 297-305. (in Chinese).

[14] GB50017-2003, Code for design of steel structures. Beijing: China Planning Press, 2003. (in Chinese).
