The Strain Change Rules of Full-Scale High Strength Concrete Frame Columns with High Axial Compression Rations

Abstract:

Based on experimental study of 9 full-scale high-strength concrete(HSC) rectangular frame columns with high axial compression ratios, high-strength longitudinal reinforcements and transverse reinforcements and rectangular interlocking ties, their strain change rules of longitudinal reinforcement, stirrups and concrete were discussed and analyzed. The main results indicate as follows. The maximum tensile strain of longitudinal reinforcement decrease and the tensile strain of concrete increase quickly as the axial compression ratios and the strength grades of concrete are higher; the strains of outer stirrups are all the time greater than those of inner stirrups; the single brace stirrups have the same action with the closed stirrups.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 919-921)

Pages:

288-291

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.919-921.288

Citation:

Cite this paper

Online since:

April 2014

Authors:

Guo Jun Zhang*, Yong Bin Jia, Xi Lin Lu

Keywords:

Brace Stirrup, Failure Mode, Full Scale, High-Strength Concrete (HSC), Inner Stirrup, Outer Stirrup

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Chen Zhaoyuan. The development and application of high strength and performance concrete [J]. Journal of Civil Engineering, 1997, 30(5): 3-11. (in Chinese).

Google Scholar

[2] ZHANG Guojun, DU Xiaoqin, and etc. The Failure Modes Analysis of Full-Scale High Strength Concrete Frame Columns with High Axial Compression Ratios [J]. ENGINEERING MECHANICS, DEC. 2008, Vol. 25 No. S, 2009. 26(SⅠ): 89-93. (in Chinese).

Google Scholar

[3] ZHENG Shan-suo, DENG Guo-zhuan, and etc. Experimental Study on Seismic Behaviors of Steel Reinforced High Strength and High Performance Concrete Frame [J]. ENGINEERING MECHANICS, 2009, 26(5): 88-101.

Google Scholar

[4] Guojun Zhang, Boquan Liu, Guoliang Bai，Jianxin Liu. Experimental Study on Seismic Behavior of High Strength Reinforced Concrete Frame Columns with High Axial Compression Ratios [J]. Structural Engineering and Mechanics，2009, 33(5): 653-656.

DOI: 10.12989/sem.2009.33.5.653

Google Scholar

[5] ZHANG Guojun. Experimental research on seismic behaviors of high-strength concrete frame columns[R]. Postdoctoral Come-out-Station Reports of Tongji University, Shanghai: Tongji University, 2006. ( in Chinese).

Google Scholar
