Simulated Trajectories of Particles and the Number of Particles Trapped by the Circulating Filter in a Hard Disk Drive

Abstract:

The particle trajectories and the number of them trapped by circulating filter of a 2.5 inch dual platter hard disk drive (HDD) were numerically investigated using a transition shear stress transport turbulence model (transition SST). Four head gimbal assemblies (HGAs) were placed at the outer diameter positions where tiny particles of alumina were released. The simulation revealed the results of airflow, particle trajectories and efficiency of a circulating filter. This result can be applied as fundamental information to design HDD layout in order to reduce its contamination. Keywords: Airflow, Circulating Filter, Hard Disk Drive, Particle Trajectory, Computational Fluid Dynamics

• Periodical: Advanced Materials Research (Volumes 931-932)
• Pages: 1058-1062
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.931-932.1058
• Online since: May 2014
• Authors: Jatuporn Thongsri*, Vana Pongkom
• Keywords: Airflow, Circulating Filter, Computational Fluid Dynamics (CFD), Hard Disk Drive, Particle Trajectory

References

[1] Y. Shiroishi, K. Fukuda, I. Tagawa, H. Iwasaki, S. Takenoiri, H. Tanaka, H. Mutoh, N. Yoshikawa, Future option for HDD storage, IEEE Trans. Magn. 45 (2009) 3816-3822.

DOI: 10.1109/tmag.2009.2024879

[2] L. Darius, S. Bolasna, J. Kotla, R. Simmons, Y. Iihara, T. Matsumoto, A. Tobari and H. Tsuchida, Introduction of femto slider in mobile disk drive, IEEE Trans. Magn. 40 (2004), 349-352.

DOI: 10.1109/tmag.2003.821153

[3] H. S. Park, Y. C. Yoo, G. N. Bae and J. H. Hwang, Investigation of particle generation in a hard disk drive dusing the start/stop Period, IEEE Trans. Magn. 35 (1999), 2439-2441.

DOI: 10.1109/20.800851

[4] D. Y. Lee, J. Hwang and G. N, Bae, Effect of disk rotational speed on contamination particles generated in a hard disk drive, Microsyst. Technol. Vol. 10 (2004) 103-108.

DOI: 10.1007/s00542-003-0327-6

[5] X. Shen and D. B. Bogy, Contact force and frictional heating due to large particles in hard disk interface, ASME J. Tribol., 130 (2008) 011015-1-7.

DOI: 10.1115/1.2805438

[6] N. Liu, Z. He, C. K. T. Chow and H. T. Loh, A numerical investigation of particle trajectory inside hard disk drive, IEEE Trans. Magn. 47 (2011), 1890-1892.

DOI: 10.1109/tmag.2011.2141121

[7] N. Liu, Q. Zhang and K. Sundaravadivelu, A numerical simulation of particle trajectory in thin hard disk drive, IEEE Trans. Magn. 49 (2013), 2590-2593.

DOI: 10.1109/tmag.2013.2257994

[8] S. E. Park, D. Y. Lee, J. H. Park, T. S. Kang, J. G. Yoo and J. Hwang, Design and performance test of comb-shaped clamp/spacer for improvement of recirculating filter efficacy in a hard disk drive, IEEE Trans. Magn. Vol. 45 (2009), 201-205.

DOI: 10.1109/tmag.2008.2005520

[9] J. Thongsri, Comparison of k-ε turbulence models for predicting airflow in 3. 5-inch dual platter hard disk drive, Proc. Int. Conf. Engineering, Applied Science, and Technology, (2013), 1-5.

[10] Ansys Fluent 14. 5, User's guide, Chapter 4 Turbulence, (2012).

[11] Information on http: /www. hepafilters. com.
