Heat Transfer Augmentation in a Round Tube with 60^o Winglet Pair Inserts

Abstract:

The experimental study on heat transfer enhancement in a tubular heat exchanger fitted with 60^o winglet pairs is carried out by varying airflow velocity in turbulent region in the test section having a constant wall heat-flux. Effects of three blockage ratios (BR=e/D= 0.1, 0.15 and 0.2) and three pitch ratios (PR=P/D= 1, 1.5 and 2) of the winglet pairs on heat transfer rates in the terms of Nusselt number (Nu) and pressure loss in the form of friction factor (f) are examined. The experimental results illustrated that the tube with winglet pair insert provides the heat transfer rate higher than the smooth tube around 1.7 to 2.6 times, depending upon operating conditions. The thermal enhancement factor for using the winglet-pair turbulator is in a range of 1.03 - 1.31.

• Periodical: Advanced Materials Research (Volumes 931-932)
• Pages: 1188-1192
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.931-932.1188
• Online since: May 2014
• Authors: Suriya Chokphoemphun, Pattarapan Tongyote, Pongjet Promvonge*, Withada Jedsadaratanachai, Teerapat Chompookham
• Keywords: Counter-Vortex, Friction Factor, Nusselt Number, Thermal Performance, Winglet

References

[1] S.W. Chang, K.W. Yu, M.H. Lu, Heat transfer in tubes fitted with single, twin and triple twisted tapes, Exp. Heat Tran., 18, (2005), 279–294.

DOI: 10.1080/08916150500201560

[2] P. Promvonge, Thermal performance in circular tube fitted with coiled square wires, Energy Conversion and Management 49 (5) (2008) 980–987.

DOI: 10.1016/j.enconman.2007.10.005

[3] A. Durmus, Heat transfer and exergy loss in cut out conical turbulators, Energy Conversion and Management 45 (5) (2004) 785–796.

DOI: 10.1016/s0196-8904(03)00186-9

[4] S. Eiamsa-ard and P. Promvonge, Influence of Double-sided Delta-wing Tape Insert with Alternate-axes on Flow and Heat Transfer Characteristics in a Heat Exchanger Tube, Chinese Journal of Chemical Engineering, 19 (3) (2011) 410-423.

DOI: 10.1016/s1004-9541(11)60001-3

[5] T. Chompookham, C. Thianpong, S. Kwankaomeng, P. Promvonge, Heat transfer augmentation in a wedge-ribbed channel using winglet vortex generators, International Communications in Heat and Mass Transfer, 37 (2010) 163–169.

DOI: 10.1016/j.icheatmasstransfer.2009.09.012

[6] G. Tanda, Heat transfer in rectangular channel with transverse and V-shaped broken ribs. International Journal of Heat and Mass Transfer 47 (2004) 229-243.

DOI: 10.1016/s0017-9310(03)00414-9

[7] ASME, Standard Measurement of fluid flow in pipes using orifice, nozzle and venture, ASME MFC–3M-1984, United Engineering Center 345 East 47th Street, New York, (1984), 1–56.

[8] ANSI/ASME, Measurement uncertainty, PTC 19, Part I, (1986), 1–(1985).

[9] F.B. Incropera, P.D. Witt, T.L. Bergman, A.S. Lavine, Fundamentals of Heat and Mass Transfer, John-Wiley & Sons, (2006).
