Analysis of Hydraulic Prop High Frequency Induction Cladding Temperature Field

Abstract:

The temperature field of mobile column is simulated, with the theory of high frequency induction heating and fourier heat conduction law , to analyze the change law of the temperature field with time, with different cladding parameters. The results show that the induction heating speed is mainly affected by power frequency of high frequency induction heating and cladding current. The higher frequency induction heating power is or the larger the cladding current is, the the faster the surface temperature of hydraulic prop is rising, the lower the inside-wall termperature and the less influenced the matrix is. The effect and the efficiency of cladding is comparatively superior when cladding frequency is 250KHz and current is 1160A.

• Periodical: Advanced Materials Research (Volume 936)
• Pages: 1657-1661
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.936.1657
• Online since: June 2014
• Authors: Fu Dong Zhu*, Bi Yun Zhu, Bin Liu
• Keywords: High Frequency Cladding, Hydraulic Prop, Temperature Field

References

[1] ZHAO Wenqiang, MIAO Hongbin et al. Study on laser cladding strengthening technology for mine hydraulic props. mining machinery, 2011, 12: 18-20.

[2] WANG Lichu, Cteate Problems of Hydraulic Prop Analysis. Coal Mine machinery, 2010, 08, 145-146.

[3] YU Shanqi, Research on Remanufacturability of Mine Hydraulic Prop. Coal Mine machinery, 2012, 03, 49-51.

[4] WANG Chao, LYU Zhi, XIAO Hongbing, Coal Mine Hydraulic Pillar Surface Treatment Process Innovation. Coal Mine machinery, 2013, 02, 122-124.

[5] LIU Xiangqing, GUOZhimeng, GAO Kewei et al. Microstructure and corrosion resistance of Ni60 coating prepared by induction cladding. Transactions of Materials and Heat Treatment, 2012, 33(supplement)：309-312.

[6] HE Dingyong, XU Jing, MA Ran et al. Properties of WC reinforced Ni60 coating prepared by high frequency induction cladding. Transactions of Materials and Heat Treatment, 2008, 29(3)：138-141.

[7] T. Umeda, P. Thirathipviwat, M. Supradist et al. Microsegregation development of heavily electromagnetically stirred melt of super high strength Al-10Zn-2. 5Mg-2. 3Cu alloy. International Journal of Cast Metals Research, 2011, 24(3)：184-189.

DOI: 10.1179/136404611x13001912814022

[8] M. Hazra, A.K. Mondal, S. Kumar et al. Laser surface cladding of MR1 153M magnesium alloy with (Al+Al2O3). Surface & Coatings Technology, 2009, 203(16)：2292-2299.

DOI: 10.1016/j.surfcoat.2009.02.022

[9] FU Zheng-bo. Induction Heating and Energy Conservation—the Design and Application of Induction Heater. Beijing: Mechanical Industry Press, 2008: 11-97.

[10] JIN Xiao-shu, YANG Xi-chen, FENG Li-wei et al. Numerical simulation of coaxial powder flow with carrying gas in laser manufacturing. Chinese Journal of Mechanical Engineering, 2007, 43(5): 161-166.

DOI: 10.3901/jme.2007.05.161

[11] J.P. Park, M.G. kim, U.S. Yoon, W.J. Kim. Microstructures and mechanical properties of Mg-Al-Zn-Ca alloys fabricated by high frequency electromagnetic casting method. Journal of Materials Science, 2009, 44: 47-54.

DOI: 10.1007/s10853-008-3130-z

[12] The Compiling Group of Mechanical Manufacturing Process Materials Technic Directory. Mechanical Manufacturing Process Materials Technic Directory. Beijing: Mechanical Industry Press, 1992: 265-269.
