Calculating Fatigue Life of Helicopter Composite Blades Based on the Residual Strength Theory

Abstract:

This paper presents a method for calculating the fatigue life of helicopter composite material blade with residual strength theory. Builded the residual strength model, analyzed the influence of loading sequence, tensile -- compressed between the conversion and failure probability, adopt corresponding treatment plan. Using the model of residual strength, selected 19 typical flight condition, using the "rain flow counting method" load matrix, finally get the helicopter load spectrum. The composite blade dangerous section are calculated (root maximum strain), combined with every moment and centrifugal force, the flight state determined blade the stress spectrum, then according to the blade model and material characteristic parameters were calculated, results show that the residual strength decreases with the increase of flight time, and the failure probability increased with the flight time increasing. By comparison, the calculation results and full size is consistent with the experimental results, which shows the calculation is reliable.

• Periodical: Advanced Materials Research (Volumes 941-944)
• Pages: 1552-1557
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.941-944.1552
• Online since: June 2014
• Authors: Wei Wang, Yu Lin Zhu, Qi Min Xiao*
• Keywords: Composite Material, Fatigue Life, Helicopter Blades, Residual Strength Theory

References

[1] Broutman L J, Sahu S. A new theory to predict cumulative fatigue damage in fibreglass reinforced plastics[R]. Composite Materials: Testing and Design (2nd Conference): ASTM STP497, Philadelphia, American Society for Testing and Materials, 1972: 170-188.

DOI: 10.1520/stp27746s

[2] Yang J N, Liu M D. Residual strength degradation model and theory of periodic proof tests for graphite epoxy laminates[J]. Journal of Composite Material, 1977, 11(2): 176-203.

DOI: 10.1177/002199837701100205

[3] Hashin Z. Cumulative damage theory for composite materials: residual life and residual strength methods[J]. Composites Science and Technology, 1985, 23: 1-19.

DOI: 10.1016/0266-3538(85)90008-9

[4] Charewicz A M, Danile I M. Damage mechanisms and accumulation in graphite epoxy laminates[R] Composite materials: fatigue and fracture: ASTM STP 907. Philadelphia: American Society for Testing and Materials, 1986: 274-297.

DOI: 10.1520/stp19991s

[5] Schaff J R, Davidson B D. Life prediction methodology for composite structures: Part I Constant amplitude and two stress level fatigue[J]. Journal of Composite Materials, 1997, 31(2): 128-157.

DOI: 10.1177/002199839703100202

[6] Weixing Yao. The fatigue life of structure [M]. Beijing: National Defence Industry Press, 2003: 212-218. ( In Chinese).

[7] Yi Gu. Tensile residual strength and distribution [J]. Journal of Nanjing University of Aeronautics & Astronautics, 1994, 31(2): 164-171. ( In Chinese).

[8] Jung-Ho Kwon, Kyung-Jung Hwang, Seok-Soo Kim, Pan-Jo Kim, Choon-Sam Kim. Fatigue Life Evaluation in Composite Rotor Blade of Multipurpose Helicopter, Aerospace Techniques and Shipbuilding, KORUS，2002, 15~20.

DOI: 10.1109/korus.2002.1027948

[9] Xiaoping Luo. [J]. mechanical strength calculation of fatigue life of helicopter composite material blade, 2012, 34(2): 292-297. ( In Chinese).
