Experimental Study on Three-Dimensional Flexible Stretch Bending Formability for Complex Cross-Sectional Profiles of TWB

Abstract:

Taking the upper strip of automobile doorframe which is complex profiles roll bending part of high-strength steel welded blanks as the research object, and then to Investigate its three-dimensional flexible stretch-bending formability under force control mode; the law of tensile force and clamp rotation angles’ influences on forming precision of the product is obtained. The results show that the springback of the line contour precision is largely affected by the comprehensive impact of tensile force and the clamp rotation angles, the values mentioned above reached minimum when the tensile force is 1.1 times the material yield strength, the springback will increase when greater or less than this value. Because of the surface torsion springback, internal and external surface contour accuracy mainly affected by the stage rotation angle when the profile bending curvature is large enough, and the effect is not obvious when the bending curvature is small.

• Periodical: Advanced Materials Research (Volumes 941-944)
• Pages: 1710-1714
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.941-944.1710
• Online since: June 2014
• Authors: Ya Jing Shen*, Qin Xiang Xia, Guo Feng Zhong, Feng Wu
• Keywords: 3D Flexible Stretch-Bending, Complex Profiles, Force Control Mode, Forming Precision, High-Strength Steel Welded Blanks

References

[1] Zeng Ji: Optimization design of the door structure based on the lightweight. Chang sha: Hu nan University (2012). (In Chinese).

[2] Zhai jian jun et al: Sheets and profiles stamping and forming technology, Beijing: Mechanical Industry Press (2008). (In Chinese).

[3] Zhou Xianbin, DiaoKeshan, LiXiaoxing, Jin Chaohai: Journal of Beijing University of Aeronautics and Astronautics 2006. 10, 32(10): 1168-1173. (In Chinese).

[4] Jun Zhao, Ruixue Zhai, Zhiping Qian, Rui Ma: International Journal of Mechanical Sciences 75(2013), 45-54.

[5] Miller J E, Kyriakides S, Bastard A H: International Journal of Mechanical Sciences, 2001, 43: 1319-1338.

[6] J.E. Miller, S. Kyriakides, A.H. Bastard: International Journal of Mechanical Sciences 43(2001): 1283-1317.

[7] A.A. Elsharkawy, A. A EL-Domiaty: Journal of Materials Processing Technology 110(2001): 265-176.

[8] Zhou Miaomiao, Wang Hongjian, He Erming, Wang Yongjun, Qiu Zhixue: Mechanical Science and Technology for Aerospace Engineering, 2012. 6, 31(6): 888-892. (In Chinese).

[9] Zhou H, He E M, Wang Hong jian: Science Technology and Engineering, 2010, 1671-1815(14). (In Chinese).

[10] Shen Y J, Xu Z X, Xia Q X, Wu F, Zhong G F: Die&Mould Manufacture, 2014, 150(1): 29-34. (In Chinese).
