Finite Element Analysis of Structural Strength of Concrete Mixing Truck’s Frame

Abstract:

The finite element model of the concrete mixing truck’s frame is builded by using shell as basic element, and the process of building the finite element model of the balance suspension is introduced in detail. Based on this, frame’s stress on five types of typical operating conditions are calculated by using the finite element analysis software, NASTRAN, and results can show the dangerous position and the maximum stress position on the frame. The analysis result on structural strength can provide the basis for further improving the frame structure.

• Periodical: Advanced Materials Research (Volumes 945-949)
• Pages: 1143-1149
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.945-949.1143
• Online since: June 2014
• Authors: Hai Xia Sun, Hua Kai Wei, Xiao Fang Zhao, Jia Rui Qi
• Keywords: Concrete Mixing Truck, Finite Element Analysis (FEA), Frame

References

[1] GB3273-89, the State Standard of the People's Republic of China (hot-rolled sheet steel for automotive frame) [S], in Chinese.

[2] Haixia Sun and Dawei Liu, Manufacture Information Engineering of China, 2007. Vol. 3. Pages33-36, in Chinese.

[3] Zhenguo Dong, Strength Analysis of Finite Elements of Semi-trailer Tractor's Frame, Qingdao: Qingdao University, 2005, in Chinese.

[4] Jiao Wang. Strength Analysis and Lightweight Optimization Study on Special Heavy Vehicle Frame, Wuhan University of Technology, 2005, in Chinese.

[5] Jinbo Li and Zhongjian Zhou, Shanghai Auto, 1998. Vol. 1. Pages29-30, in Chinese.

[6] Dexin Li, Jiangtao Lv and Jinchun Ying, Mechanical Science and Technology, 2002. Vol. 3. Pages380-383, in Chinese.
