Study on Aerodynamic Layout of Two-Dimension Trajectory Correction Projectile

Abstract:

To research aerodynamic layout of the two-dimensional correct projectile, the model of projectile under different aerodynamic layout was established. Various kinds of aerodynamic dates were obtained through aerodynamic simulation. Through the establishment of suitable for two-dimensional modified ballistic model of the projectile, the capability of correcting has been received for the different layouts of the rudder. The simulation results show, to meet the aerodynamic layout of the two-dimensional correct projectile and flight stability, the rudder is closer to the head of the projectile, the correction ability is better.

• Periodical: Advanced Materials Research (Volumes 945-949)
• Pages: 1619-1622
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.945-949.1619
• Online since: June 2014
• Authors: Jia Yi Zhang*, Xiao Yu Wang, Yong Ping Hao, Yu Yang Guo
• Keywords: Correction Projectile, Drag Coefficient, Lift Coefficient, Trajectory Correction

References

[1] Xin Wang: Study on Intelligent Control and Correction Method of Missiles Precision[D], 2010. (In Chinese).

[2] Heng Liu and Pengfei Huo: Journal of Detection and Control, Vol. 31(2009), pp.47-50. (In Chinese).

[3] Zipeng Han: Missiles Exterior Ballistics[M], Beijing: Beijing Institute of Technology Press, 2008, pp.141-143. (In Chinese).

[4] Mingyou Xu: Rocket Exterior Ballistics[M], Harbin: Harbin Institute of Technology Press, 2004, pp.10-15. (In Chinese).

[5] Wenxing Lei and Xiaoli Tian: Journal of Projectiles, Rockets, Missiles and Guidance, Vol. 32(2012), pp.131-135. (In Chinese).

[6] William J. Larkin and Mitch Thomas: Journal of Guidance and Control, Vol. 2(1979), p: 382-387.
