The Systematic Study of Music Spectrum Display Based on FFT

Abstract:

Spectrum analysis is the superposition signal intodifferent frequency component and the imaginary indexcomponent, the analysis of signal from the frequency point of view. It is widely used in voice processing, image processing, digital audio, seismic exploration. The FFT algorithm, provides an effective solution forreal-time processing of frequency domain analysis. Music display system based on FFT spectrum, the main work is as follows:First, the fast Fourier transform ideas a brief description, and combined with the specific hardware and software implementations of the algorithm of the system used by the fast Fourier transform is described in detail. Then, describes the main hardware devices used in the system, including STC12C5A60S2 chips, display principle Principle 32 * 64LED dot matrix screen, use 74LS595 and 74LS164's. The system is simple, easy to use, you can use STC12C5A60S2 SCM data processing functions of the sound signal spectrum analysis.

• Periodical: Advanced Materials Research (Volumes 945-949)
• Pages: 1764-1767
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.945-949.1764
• Online since: June 2014
• Authors: Lin Jin, Qiu Lei Du
• Keywords: DFT, FFT, Signal Processing, Spectrum Analysis

References

[1] N. Yi guang, Single-chip microcomputer principle and interface technology [M], Beijing: Publishing House of electronics industry,  2008: 32-79.

[2] Serial Infrared Link Access Protocol(IrLAP), Version 1. 1. June 16, 1996, IBM Corporation , Hewlett-Packard Company, Apple Computer, Inc., Counterpoint Systems Foundry, Inc.

[3] Jimemez Petal. Improved PPM schemes for infrared wireless LAN [J]. Electronics Lettrs, 1996, 10.

[4] W Tianmiao. Examples of embedded systems design and development (3rd edition) Beijing: Tsinghua University press, (2008).

[5] Ma Zhongmei, MCU C language application programming (4rd edition), Beijing: Beijing university of aeronautics and astronautics press, (2007).
