Finite Element Analysis of Hydraulic Clipping Machine Shear Platform Dased on ANSYS

Abstract:

Q43Y-85D type crocodile hydraulic clipping machine was taken as research object to optimization design. A finite element model for clipping machine was built using shell unit as fundamental unit. ANSYS12.0 finite element method was used to analyze the deformation and stress distribution of the shear platform model of hydraulic clipping machine. The result showed that the maximum equivalent stress at the dangerous area was 368.162 MPa and the maximum elastic strain was 0.1814×10^-2 mm. After the structural optimization design, it was found that the maximum equivalent stress decreased to 186.238 MPa which did not exceed the material’s yield limitation 215 MPa and the maximum elastic strain decreased to 0.919×10^-3 mm which satisfied the requirement of stiffness.

You might also be interested in these eBooks

Advances in Manufacturing Science and Engineering V

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 945-949)

Pages:

190-193

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.945-949.190

Citation:

Cite this paper

Online since:

June 2014

Authors:

Hai Lin Wang, Yi Hua Sun*, Ming Bo Li, Gao Lin, Yun Qi Feng, Shi Li Wu, Cai Hua Huang, Jian Chen

Keywords:

ANSYS Finite Element Analysis, Shear Platform, Shell Unit, Structure Optimization

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author
