The Application of Sliding Mode Control in Current Source Converter

Abstract:

Current source converter is a variable structure system due to its switching nature, so that it can easily cause the output current waveform distortion and can not be accurately track the reference current. To solve the above problems, this paper proposes a new variable structure control strategy with fan-shaped sliding domain in the current source converter control system. In the control strategy, the paper deduces the switching surface and switching control law of SMVSC, and calculates the sliding existence domain based on the mathematical model of current source converter. Finally, the simulation results show that the control scheme can make current source converter have better output current waveform, fast tracking the reference current, and strong anti-interference ability. Therefore, the control scheme is correct, effective and feasible.

• Periodical: Advanced Materials Research (Volumes 945-949)
• Pages: 2331-2337
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.945-949.2331
• Online since: June 2014
• Authors: Jing Bai, Shi Qi Lu*, Jian Liu
• Keywords: Current Source Converter (CSC), Nonlinear System, Sliding Mode Variable Structure Control, Variable-Rate Reaching Law
