Full-Bridge ZVZCS Converter Design Based on Power System

Abstract:

It is very common that the power consumption is too high and the efficiency ratio is too low in the field of the current full-bridge ZVZCS Converter, thus a practical circuit topology is designed and its working process is analyzed to solve the problem. The converter lead pipe can achieve a zero voltage turn-on and turn-off by using MOSFET, and a zero current turn-on and turn-off lagging by using IGBT. By analyzing the relevant waveform of the converter, the correctness of the converter designed is verified.
