Equipment Design for Classroom Electrical Monitor Based on Power Line Carrier Communication

Abstract:

In order to monitor the classroom electrical power usage and achieve low-carbon energy. A kind of monitor equipment was designed by using STM32F103RBT6 as main controller and BWP09 power carrier communication module as the carrier communication media. Using this device, all of electrical appliances in classrooms such as fan, light and air conditioning were under remote centralized control. The control system can turn on or turn off devices and monitor working state of each electric appliance. When electric appliance break down, the system will alarm and send data back to the control room. Waste of electric of energy and burden of classroom administrators were reduced by using this device. Experimental results suggested that the classroom electrical appliance monitor work was stable and reliable, having practical popularized value.

• Periodical: Advanced Materials Research (Volume 952)
• Pages: 244-248
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.952.244
• Online since: May 2014
• Authors: Zhi Jian Zhang*
• Keywords: BWP09, Monitor, Power Line Carrier Communication, STM32F103
