Studies on Improving the AC Outward Transmission Capacity of Sichuan Power Grid by Utilization of Phase-Shifting Transformers

Abstract:

In this paper, the feasibility analysis of the utilization of phase shifting transformers (PSTs) to improve the AC outward transmission capacity of Sichuan power grid (SCPG) is presented. Firstly, the authors analyze the working principle of PST, as well as the rules for selecting its location. Then, the AC outward transmission limit of SCPG is studied with PSASP software. Finally, the PST is used to change the power flow distribution of lines on border of SCPG. Simulations results show that the PST can significantly improve the AC outward transmission capacity of SCPG. At the same time, short-circuit current of SCPG is also reduced.

• Periodical: Advanced Materials Research (Volumes 960-961)
• Pages: 1000-1005
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.960-961.1000
• Online since: June 2014
• Authors: Gang Chen*, Fan Tang, Yu Fei Teng, Hua Zhang, Li Jie Ding
• Keywords: Phase Shifting Transformer, Power Flow, Sichuan Power Grid, Transmission Capability

References

[1] Z. X. Xu, W. T. Zhang, G. Wang, et al. Application of phase-shifter for power flow control of parallel transmission lines. Power System Technology, 1996, vol. 20, no. 4, pp.6-10.

[2] X. Q. Zhao, M. X. Guo. Study of installation of phase-shifting transformers for East China Power Grid. East China Electric Power，2006, vol. 34, no. 11, pp.32-34.

[3] S. Q. Ni. Study on basic design and electromagnetic transient of UHV static phase shifter. Beijing: China Electric Power Research Institute, 2013.

[4] W. J. Lyman, J. R. North. Application of large phase-shifting transformer on an interconnected system loop. Transactions of the American Institute of Electrical Engineers, 1938, vol. 57, no. 10, pp.579-588.

DOI: 10.1109/t-aiee.1938.5057744

[5] R. Ogahara, Y. Kawaura, S. Iwamoto. Using phase shifters for power flow adjustment following large-scale generation loss. IEEE PES General Meeting, Canada, 2013, pp.1-5.

DOI: 10.1109/pesmg.2013.6672324

[6] R. L. LEE, M. J. Beshir. Planning aspects of 525 kV phase shifters and static var compensators for the Mead-Phoenix and Mead-Adelanto transmission projects in the Southwestern U.S. ICPST'94, Beijing，China，1994, pp.970-978.

DOI: 10.1109/61.368366

[7] E. M. Carlini, G. Manuzio, D. Bonmann. Power flow control on the Italian network by means of phase-shifting transformers. CIGRE Session 2006，C2-206，Paris：CIGRE，2006, pp.1-12.

[8] J. Verboomen, H. D. Van, P. H. Schavemaker, et al. Phase shifting transformers: principles and applications. 2005 International Conference on Future Power Systems, Amsterdam, 2005, pp.1-6.

DOI: 10.1109/fps.2005.204302

[9] M. Belivanis, K. R. W. Bell. Use of phase-shifting transformers on the transmission network in Great Britain. 2010 45th International Universities Power Engineering Conference (UPEC), Cardiff, Wales, 2010, pp.1-5.

[10] IEEE Guide for the Application, Specification, and Testing of Phase-Shifting Transformers, IEEE Std C57. 135-2011 (Revision of IEEE Std C57. 135-2001).

DOI: 10.1109/ieeestd.2012.6238289

[11] B. Zheng, Z. T. Xiang, L. G. Ban, et al. Electromagnetic transient analysis on static phase shift applied in UHV power grid. Power System Technology, 2013, vo. 37, no. 5, pp.1373-1377.
