Research for Fuel Common Rail System about Marine Diesel Engine

Abstract:

Wartsila RT-flex 60C diesel engine is selected as the object to research pressure control of fuel common rail system, building the system simulation model, and analyzing main factors influencing rail pressure in the system. it was concluded that they were diesel engine speed, load. In the process of MATLAB/Simulink simulation, the rail pressure control logic was designed by adopting maps with the two factors as independent variables to get theory feedforward quantity of fuel rack, feedback quantity of fuel rack is obtained by fuzzy PID control. The simulation experiments show that the improved control method reduces the rail pressure fluctuation, at the same time the overshoot volume of dynamic rail pressure control is greatly reduced, response velocity quickened. The control method has been used in a Marine simulator.

• Periodical: Advanced Materials Research (Volumes 960-961)
• Pages: 1455-1459
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.960-961.1455
• Online since: June 2014
• Authors: Yuan Qing Wang*, Guang Ren, Zhi Qiang Zhou
• Keywords: Diesel Engine, Feed Forward, Fuel Common Rail, Rail Pressure Control

References

[1] Suhai Shen, Peili Wu, Hui Zhao. Modeling and simulation of common rail fuel system of electronically controlled marine diesel engine [J]. Journal of Shanghai Maritime University, 2013, 34(1): 36-40 (in Chinese).

[2] Yongjian Wang, Guohao Yang, Siqin Li. Simulation for Fuel Common Rail Systems and Rail Pressure about Electronically Controlled Marine Diesel Engines[J]. NAVIGATION OF CHINA, 2013, 36(2)：22-27(in Chinese).

[3] Tao Qiu， Yan Lei， Jing Peng, Xuchu Li. Research of rail pressure control strategy on common rail fuel system[J]. Chinese Internal Combustion Engine Engineering, 2013，34（2）：83-87(in Chinese).

[4] Mingzhi Chen, Huiru Guo, Haiyan Wang , et al. Running simulation on electronically controlled marine two-stroke high pressure common rail diesel engine[J]. Journal of Shanghai Maritime University, 2013，34（1）：41-44(in Chinese).

[5] Tao Ping, Jianxin Xu, Wenchao Fang，et al. Dynamic Characteristics investigation of High Pressure Common Rail System for Marine Diesel Engine(I)[J]. Ship Engineering, 2009, 31(3): 7-10(in Chinese).
