The Influence of Buoyancy and Heterogeneity on CO₂ Saturation in Porous Media at Reservoir Conditions

Abstract:

CO₂/water displacement process in porous media under conditions of CO₂ geological storage was observed by using X-ray CT. The porous media was a packed bed filled with glass beads. The size of the glass beads in the packed bed is 0.2mm in diameter and the flow rates were adjusted by the fractional CO₂ flow rates from 1.2 to 3.6 ml/min. The porosity and CO₂ saturation were measured during the packed bed flooding experiments under conditions of two-phase of CO₂ and brine (P ~ 8.0 MPa and T = 40°C). The observation results show that the CO₂ displacement efficiency is strongly affected by the heterogeneity of the packed bed. However, it is the buoyancy that plays a key role on governing the CO₂ saturation distribution, which was observed from the experiments under variant of fractional flow rates. The results obtained from this study, especially the CO₂ saturation distribution, provided informations on further investigating the mechanism of the movement and immobilization of CO₂ plumes for CO₂ geological storage.

• Periodical: Advanced Materials Research (Volumes 962-965)
• Pages: 1641-1644
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.962-965.1641
• Online since: June 2014
• Authors: Zi Jian Shen, Yu Liu*, Yong Chen Song
• Keywords: Buoyancy, Heterogeneity, Porous Media, Two-Phase Flow, X-Ray CT Scan

References

[1] Shi, J. -Q., Z. Xue, et al. . Supercritical CO2 packed bed flooding and imbibition in Tako sandstone - Influence of sub-packed bed scale heterogeneity. International Journal of Greenhouse Gas Control , 2011, 5(1): 75-87.

DOI: 10.1016/j.ijggc.2010.07.003

[2] Perrin, J. -C. and S. Benson. An Experimental Study on the Influence of Sub-packed bed Scale Heterogeneities on CO2 Distribution in Reservoir Rocks. Transport in Porous Medium , 2009, 82(1): 93-109.

DOI: 10.1007/s11242-009-9426-x

[3] Uemura, S., R. Kataoka, et al. Experiment on liquid and supercritical CO2 distribution using micro-focus X-ray CT for estimation of geological storage. Energy Procedia , 2011, 4: 5102-5107.

DOI: 10.1016/j.egypro.2011.02.485

[4] Samuel C. M. Krevor, Ronny Pini, Lin Zuo and Sally M. Benson. Relative permeability and trapping of CO2 and water in sandstone rocks at reservoir conditions. WATER RESOURCES RESEARCH, VOL. 48, W02532, doi : 10. 1029/2011WR010859 , (2012).

DOI: 10.1029/2011wr010859

[5] Akin, S., Kovscek, A.R.: Computed tomography in petroleum research. In: Mees, F., Swennen, R., Van Geet,M., Jacobs P. (eds. ) Application of X-ray Computed Tomography in the Geosciences, p.23–38. Geo-logical Society of London, (2003).

DOI: 10.1144/gsl.sp.2003.215.01.01

[6] Kuo, C-W, Perrin, J-C., and Benson, S. Effect of gravity, flow Rate, and small scale heterogeneity on multiphase heterogeneity on multiphase flow of CO2 and brine, 2010, SPE132607.

DOI: 10.2118/132607-ms
