A New Springback Compensation Method for Sheet Metal Bending Based on Curvature Correction

Abstract:

The dimensional inaccuracy caused by springback is a major problem for most stamping applications. One of the most promising ways to solve this problem is to compensate it by means of appropriate tool shape modifications. In this paper, a new springback compensation method is introduced. A coefficient of curvature correction, which reflects the deviation of the experiment data and the analytical calculation data, is also proposed to redesign the tooling shape. This method was applied to a two-dimensional wavy-shaped part forming case for verification. The experiment results demonstrated that this method is efficient.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 130-134
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.130
• Online since: March 2010
• Authors: Juan Liao, Chi Zhou, Feng Ruan, Yin Zhu
• Keywords: Bending, Compensation, Curvature Correction, Springback

References

[1] Peng Chen: Journal of Manufacturing Science and Engineering, Vol. 130/041006 (2008), pp.1-9.

[2] Karafillis AP: Int. J. of Machine Tools & Manufacture Vol. 36 No. 4 (1996), pp.503-36.

[3] Wagoner RH, Gan W, Mao K, Price S: The sixth international EASFORM conference (2003).

[4] T.X. Yu and W. Johnson: Int. J. Mech, Sci, Vol. 23 (1981), pp.583-594.

[5] Jiaqi Wu: Journal of Applied Sciences, Vol. 21 No. 3 (2003), pp.258-262.
