Effects of the Gear Tooth Modification on the Nonlinear Dynamics of Gear Transmission System

Abstract:

The effects of tooth modification on the nonlinear dynamic behaviors are studied in this paper. Firstly, the static transmission error under load combined with misalignment error and modification are deduced. These effects can be introduced directly in the meshing stiffness and static transmission error models. Then the effect of two different type of tooth modification combined with misalignment error on the dynamic responses are investigated by using numerical simulation method. The numerical results show that the misalignment error has a significant effect on the static transmission error. The tooth crowning modification is generally preferred for absorbing the misalignment error by comparing with the tip and root relief. The tip and root relief can not resolve the vibration problem induced by misalignment error but the crowning modification can reduce the vibration significantly.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 2764-2769
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.2764
• Online since: March 2010
• Authors: Si Yu Chen, Jin Yuan Tang, C.W. Luo
• Keywords: Dynamic Load Factor, Gear, Nonlinear, Tooth Modification, Transmission Error (TE)

References

[1] E.N. Mohamad, M. Komori, H. Murakami, A. Kubo, and S.P. Fang, Journal of Mechanical Design 131 (2009): 061015-9.

[2] M. Maatar, and P. Velex, Journal of Mechanical Design, Transactions of the ASME 119 (1997): 474-480.

[3] H.H. Lin, D.P. Townsend, and F.B. Oswald, Profile modification to minimize spur gear dynamic loading, Publ. by American Soc of Mechanical Engineers (ASME), Chicago, IL, USA, 1989, pp.455-465.

[4] P. Wagaj, and A. Kahraman, Journal of Mechanical Design 124 (2002): 501-510.

[5] M. Hotait, and A. Kahraman, Journal of Mechanical Design 130 (2008): 074502-5.

[6] F.L. Litvin, Q. Lian, and A.L. Kapelevich, Computer Methods in Applied Mechanics and Engineering 188 (2000): 363-390.

[7] H. Duzcukoglu, Materials & Design 30 (2009): 1060-1067.

[8] F. Karpat, and S. Ekwaro-Osire, Tribology Transactions 51 (2008): 581-588.

DOI: 10.1080/10402000802011703

[9] H. Duzcukoglu, and H. Imrek, Engineering Fracture Mechanics 75 (2008): 4431-4438.

[10] J.H. Liu, and S.L. Chang, Research on Gear Plunge Shaving for Gears with Tooth Modifications. Imecs 2009: International Multiconference of Engineers and Computer Scientists, Vols I and Ii (2009): 1845-1850.

[11] H.H. Lin, F.B. Oswald, and D.P. Townsend, Mechanism and Machine Theory 29 (1994): 1115-1129.

[12] K. Umezawa, The performance diagrams for the vibration of helical gears, International Power Transmission and Gearing Conference, ASME, Chicago, 1989, pp.399-408.

[13] Y. Cai, and T. Hayashi, Advancing power transmission into the 21 st century (1992): 453-460.

[14] Y. Zhang, and Z. Fang, Journal of Mechanical Design 119 (1997): 120-126.

[15] F. Litvin, and A. Fuentes, Gear geometry and applied theory, Cambridge Univ Pr, (2004).

[16] A. Kahraman, P. Bajpai, and N.E. Anderson, Journal of Mechanical Design 127 (2005): 656-663.

[17] H. Lin, F. Oswald, and D. Townsend, Mechanism and Machine Theory 29 (1994): 1115-1129.

[18] H. Lin, D. Townsend, and F. Oswald, NTIS, SPRINGFIELD, VA(USA), 1987, 22 (1987).

[19] A. Kahraman, and R. Singh, Journal of Sound and Vibration 146 (1991): 135-156.
