The Electric Car Charger Control Circuit Design and Analysis Module

Abstract:

the article introduces theelectric car charger control circuit design thinking and ideas, the controlcircuit to be able to with the front-end circuit switching power supply and MCUto cooperate to complete the following phases the constant current and constantvoltage charging battery automatic conversion, and stable in each phase of thecurrent value or the voltage value. Analyze the circuit module, includingsampling module, PWM signal module, proportional amplifier module, PIadjustment module.

• Periodical: Advanced Materials Research (Volumes 971-973)
• Pages: 942-945
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.971-973.942
• Online since: June 2014
• Authors: Ying Chun Liu*, Jian Ming Zhang, De Long Zhang, Yan Yu Wang, Chun Guang Hou, Zi Ping Wang, Hua Xin Liu, Chun Rui Liu
• Keywords: Charger, Control Circuit, Electric Car

References

[1] Huazhong University of Science College, Kang Guanghua electronic technology infrastructure (analog part) [M] Fourth Edition Beijing: Higher Education Press, 1999: 277-310.

[2] Wang Yuan analog electronic technology [M] first edition Beijing: Mechanical Industry Press, 1994: 312-317.

[3] Department of Electronics, Zhejiang University, Zheng Jialong, Wang Xiaohai other analog integrated electronic technology tutorials [M] first edition, Beijing: Higher Education Press, 2002: 213-216.

[4] North Jiaotong University Pingmin Chang Analog IC system [M] Second Edition, Beijing: China Railway Press, 1998: 167-180.
