Analysis on Wheel-Rail Contact and Rail Cracks of 50m Radio Telescope

Abstract:

In order to search the pointing accuracy degradation and the wheel-rail contact of the National astronomical observatory 50m radio telescope, according to the actual wheel-rail structure and design indicators, the wheel rail contact problem with the finite element analysis based on non-Hertz rolling contact theory is analyzed. The results show that the maximum deformation should be less than 1 mm. Then the measurement scheme of rail horizontal error and deformation is formulated. The mean value of the rail horizontal error is 2.89mm, while the maximum rail horizontal error is 1.5mm. The rail maintenance scheme is put forward after the flaw detection which finds large areas of cracks at the rail junction and the welded joint. The measurement is taken after rail maintenance; the experimental data coincide with the simulation results and then verify the correctness of the wheel-rail contact model, also the solution scheme of rail cracks. The reason for the pointing accuracy degradation is verified finally, which also can provide an effective method for the wheel-rail design and maintenance of large radio telescope.

You might also be interested in these eBooks

New Technologies for Engineering Research and Design in Industry

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 971-973)

Pages:

974-978

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.971-973.974

Citation:

Cite this paper

Online since:

June 2014

Authors:

Zhi Ping Chen, Song Gen Wang, De Qing Kong*, Ju Yong Zhang, Ya Lin Zhang, Hu Li Shi

Keywords:

Contact Analysis, Finite Element, Rail Measurement, Wheel-Rail of Radio Telescope

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Symmes A, Anderson R, Egan D: Improving the service life of the 100-meter Green Bank Telescope azimuth track. International Society for Optics and Photonics, 2008: 701238.

DOI: 10.1117/12.784935

Google Scholar

[2] Anderson R, Symmes A, Egan D: Replacement of the Green Bank Telescope azimuth track. International Society for Optics and Photonics, 2008: 701237.

DOI: 10.1117/12.784807

Google Scholar

[3] Kan F W, Antebi J: Slip and wear in multilayer azimuth track systems. International Society for Optics and Photonics, 2004: 87-97.

DOI: 10.1117/12.556576

Google Scholar

[4] Juneja G, Kan F W, Antebi J: Update on slip and wear in multi-layer azimuth track systems. International Society for Optics and Photonics, 2006: 627318.

DOI: 10.1117/12.672686

Google Scholar
