The Design of Wireless Video Monitoring System Based on FPGA

Abstract:

The wireless video monitoring system contains the video acquisition device,video transmission device,video storage device and VGA display device.In this paper,we use video acquisition device to collect video siganals in real-time.The analog video signal is transmitted by using wireless technology.The video signal is converted to a digital signal by using the dedicated A/D chip. At the same time ,the YCrCb signals will be converted into RGB signals by the format converting module.Then,the digital RGB signals are converted to analog RGB signals through the D/A,and they are finally displayed on the VGA monitor in real-time.The design mainly uses the wireless transmission technology to transmit analog video signals and uses ADV7181 to decode.The controlling system of FPGA deals with the decoded digital signals which will be transmitted to the D/A and the data finally will display in real time.

• Periodical: Advanced Materials Research (Volume 981)
• Pages: 612-615
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.981.612
• Online since: July 2014
• Authors: Ya Jie Yue*, Xiao Jing Zhang, Chen Ming Sha
• Keywords: FPGA, Monitor System, VGA, Wireless Video

References

[1] Wang Jianping: Wireless Network Technology (Tsinghua University Publications, China 2013).

[2] Lun Cuifen, Ma Jiwei and Fan Hua: Computer Design and Applications . Vol. 4(2010), p.496.

[3] Du Bo, Zhang Xin and Cai ChangQing: Computer Application and System Modeling. Vol. 6(2010), p.408.
