An Inkjet-Printed Carbon Nanotube Strain Distribution Sensor for Quasi Real-Time Strain Monitoring of Lightweight Design Materials

Abstract:

Carbon fiber-reinforced polymer (CFRP) composites are lightweight, durable, and corrosionresistive materials that are popular for constructing automotive bodies and aircraft structures. However, their heterogeneous composition and anisotropic mechanical behavior make design of their service lives challenging. To address challenges in monitoring CFRP’s structural behavior, a cheap, weightless, and reliable sensor shall be developed for CFRPs to monitor their damage-to-failure mode. In this study a carbon nanotube (CNT)-embedded thin film is inkjet-printed onto a flexible substrate and applied over a tensile testing coupon. Coupled with the algorithm of electrical impedance tomography, the sensor with 16 electrodes is able to reconstruct the strain distribution of a surface under 8 sec. Non-uniform strain distribution can also be reconstructed at strain levels down to 0.001%.

• Periodical: Advances in Science and Technology (Volume 101)
• Pages: 3-8
• DOI: https://doi.org/10.4028/www.scientific.net/AST.101.3
• Online since: October 2016
• Authors: Ying Jun Zhao*, Christoph Beisteiner, Sandra Gschossmann, Martin Schagerl
• Keywords: Carbon Nanotubes, CFRP, Electrical Impedance Tomography, Inkjet-Printed Flexible Sensor, Structural Health Monitoring

References

[1] New Materials for Manufacturing in: Technology Quarterly, The Economist Ltd. (2015).

[2] S. Hoerrmann, A. Adumitroaie, C. Viechtbauer, M. Schagerl, The effect of fiber waviness on the fatigue life of CFRP materials, Int. J. Fatigue 90 (2016) 139-147.

DOI: 10.1016/j.ijfatigue.2016.04.029

[3] K. Diamanti, C. Soutis, Structural health monitoring technique for aircraft composite structures, Prog. Aerosp, Sci. 46 (2010) 342-352.

DOI: 10.1016/j.paerosci.2010.05.001

[4] S. Yang, L. Gu, R.F. Gibson, Nondestructive detection of weak joints in adhesively bonded composite structures, Compos. Struct. 51 (2001) 63-71.

DOI: 10.1016/s0263-8223(00)00125-2

[5] P.J. Schilling, B.R. Karedla, A.K. Tatiparthi, M.A. Verges, P.D. Herrington, X-ray computed microtomography of internal damage in fiber reinforced polymer matrix composites, Compos. Sci. Technol. 65 (2005) 2071-(2078).

DOI: 10.1016/j.compscitech.2005.05.014

[6] C. Yang, A. Aneke, M. Gresil, S.O. Oyadiji, Applications of thermography and ultrasonics for detection of debonding in carbon-fibre reinforced composite panels, 5th International Workshop on Aerostructures, Manchester, (2015).

[7] L.S. Schadler, S.C. Giannaris, P.M. Ajayan, Load transfer in carbon nanotube epoxy composites, Appl. Phys. Lett. 73 (1998) 3842.

DOI: 10.1063/1.122911

[8] P.J. Harris, Carbon Nanotube Science: Synthesis, Properties and Applications. Cambridge University Press, Cambridge, UK (2009).

[9] B.R. Loyola, T.M. Briggs, L. Arronche, K.J. Loh, V. La Saponara, G. O'Bryan, J.L. Skinner, Detection of spatially distributed damage in fiber-reinforced polymer composites, Struct. Health Monit. 12 (2013) 225-239.

DOI: 10.1177/1475921713479642

[10] K.J. Loh, J. Kim, J.P. Lynch, N.W.S. Kam, N.A. Kotov, Carbon nanotube sensing skins for spatial strain and impact damage identification, Smart Mater. Struct. 16 (2007) 429-438.

DOI: 10.1088/0964-1726/16/2/022

[11] L. Mortensen, D. Ryu, Y. Zhao, K.J. Loh, Rapid assembly of multifunctional thin film sensors for wind turbine blade monitoring, Key Eng. Mater. 569 (2013) 515-522.

DOI: 10.4028/www.scientific.net/kem.569-570.515

[12] R.P. Tortorich, J-W. Choi, Inkjet printing of carbon nanotubes, Nanomaterials 3 (2013) 453-468.

DOI: 10.3390/nano3030453

[13] S. Gschossmann, Y. Zhao, M. Schagerl, Development of data acquisition devices for electrical impedance tomography of composite materials, ECCM17, Munich, Germany (2016).

[14] Y. Zhao, C. Viechtbauer, K.J. Loh, M. Schagerl, Enhancing the strain sensitivity of carbon nanotube-polymer thin films for damage detection and structural monitoring, 6th ANCRiSST, Urbana-Champaign, USA (2015).
