Analysis of the Applicable Regulations and Definition of the Procedure for the Commissioning of Enclosures for High-Precision Electronic

Abstract:

After the process of design, selection of materials, prototyping and manufacture of an enclosure intended to protect electronic systems installable outdoors, it remains to describe the behavior of these enclosures, in order to ensure that the electronics installed inside are protected from the environment in which it is installed. For this, different tests of mechanical, thermal, natural aging, artificial aging and sealing natures must be accomplished. For some of the afore mentioned examinations there are directly applicable regulations, while in more specific situations, the particularities of the enclosure and its use requirements, force to an adaptation of the procedures applied to these requirements. Based on this, a method and a test plan are proposed to make sure that the system is protected against the environmental conditions in which it is installed, both for the purposes of humidity, solid particles, mechanical or thermal stresses, as for the action of aging by ultraviolet radiation among other circumstances.

• Periodical: Advances in Science and Technology (Volume 132)
• Pages: 341-349
• DOI: https://doi.org/10.4028/p-nDRH8A
• Online since: October 2023
• Authors: Alberto Sanchidrián, Alberto Brunete, Fernando Gómez, Manuel Hueso*, Almudena Ochoa, Francisco Santos, Carolina Tank
• Keywords: 3D Printing, Additive Manufacturing, Certification Tests, Enclosures, Quality Validation

References

[1] Dunn, Mark, Peter Reid, and John Malos. 2020. "Development of a Protective Enclosure for Remote Sensing Applications—Case Study: Laser Scanning in Underground Coal Mines" Resources 9, no. 5: 56.

DOI: 10.3390/resources9050056

[2] RAMOS, Raúl Gómez; YÁÑEZ, Ana Escribano. Desarrollo de sensores medioambientales portátiles. En Workshop on Disruptive Information and Communication Technologies for Innovation. Instituto Politécnico de Bragança Campus de Santa Apolónia 5300-253 Bragança Portugal, 2019. p.14.

DOI: 10.3934/matersci.2022010

[3] UNE-EN ISO 291:2008, Plastics - Standard atmospheres for conditioning and testing (ISO 291:2008).

[4] UNE-EN IEC 61969-3:2020, Mechanical structures for electrical and electronic equipment - Outdoor enclosures - Part 3: Environmental requirements, tests and safety aspects (Endorsed by Asociación Española de Normalización in September of 2020.).

DOI: 10.3403/30363309

[5] UNE-EN 60950-22:2017, Information technology equipment - Safety - Part 22: Equipment to be installed outdoors (Endorsed by Asociación Española de Normalización in May of 2017.).

[6] UNE-EN 12600:2003, Glass in building - Pendulum test - Impact test method and classification for flat glass.

DOI: 10.3403/02726245u

[7] UNE-EN ISO 604:2003, Plastics - Determination of compressive properties.

[8] UNE-EN ISO 12048:2001, Packaging - Complete, filled transport packages - Compression and stacking tests using a compression tester.

DOI: 10.3403/02170301u

[9] UNE-EN 60529:2018, Degrees of protection provided by enclosures (IP Code).

[10] UNE-EN IEC 62368-1:2020, Audio/video, information and communication technology equipment - Part 1: Safety requirements (Endorsed by Asociación Española de Normalización in April of 2020.).

DOI: 10.3403/30379500u

[11] UNE-EN 50102, Degrees of protection provided by enclosures for electrical equipment against external mechanical impacts (IK code).

DOI: 10.3403/01763546
