Design of FLM71 Fatigue Loading Model for Fatigue Assessment of Bridge Structures

Abstract:

This paper presents the FLM71 fatigue loading model, which is suitable for fatigue assessment of bridge structures. The model is built in the form of a train set containing one locomotive and several wagons, corresponding to the equivalent load of railway bridge structures in the Czech Republic in a characteristic load combination. The model was designed on the basis of data on crossing of real train sets on several bridge structures of railway lines from different parts of the Czech Republic. The proposed model is then used in an analysis that compares the results of different methods of fatigue design of real bridge structures.

• Periodical: Advances in Science and Technology (Volume 164)
• Pages: 67-74
• DOI: https://doi.org/10.4028/p-3QEFhb
• Online since: May 2025
• Authors: Petr Miklas*, Iva Broukalova, Marek Foglar
• Keywords: Fatigue Assessment of Concrete, Fatigue Loading Model, Fatigue Loading of Bridges, Fatigue of Concrete

References

[1] Správa železnic, s.o., Archival documentation of measured bridges

[2] Správa železnic, s.o., Documentation of crossings of individual train sets over measured bridges

[3] MIKLAS, P. Fatigue resistance of concrete bridge structures. MMK 2022, 2022, pp.1323-1333 ISBN 978 80-87952-37-5.

[4] Eurocode 2: Design of concrete structures - Part 1-1: General rules and rules for buildings

[5] Eurocode 2 - Design of concrete structures - Part 2: Concrete bridges - Design and detailing rules

DOI: 10.3403/30096437

[6] fib, (2013), Model Code 2010 for Concrete Structures 2010. ISBN 978-3-433-60409-0

[7] MIKLAS, P. Recommendations for modifying concrete fatigue assessments. Young Engineers Colloquium Dresden 2023, IABSE Colloqium, 2023, pp.14-15 ISBN 978-3-85748-193-2.

[8] Eurocode 1: Actions on structures - Part 2: Traffic loads on bridges
