Fault Diagnosis of a Wind Turbine Benchmark via Statistical and Support Vector Machine

Abstract:

This paper addresses the problem of fault detection and isolation (FDI) in wind turbine benchmark model using data driven and multi-class support vector machine (SVM) approach. Since, the fault detection is fundamental for any active system, isolation is similarly vital, and identification is decisive for fault reconfiguration as well as maintenance addition to monitoring purposes. The need for man-made dynamic system to work automatically when sensor, actuator, or system faults occur was constantly developed in order to increase reliability and decrease unavailability and maintenance costs. The key step of our approach based on extraction of mean features from sensors measurements by applying the statistical methods such as moving standard deviation and the exponential weighted moving average (EWMA). The fault detection step is invoked later based on the multi-class SVM classifier that decides the presence or not of the fault. Another important contribution of this paper is the simulation of combined sensor and actuator faults simultaneously for the first time in wind turbine benchmark model. The FDI performances are illustrated through simulation study for seven different scenario tests. The results demonstrate clearly the effectiveness of statistical and SVM approach to detect and isolate single, multiple sensor and actuator faults and outperforms many results reported in the literature for solving this problem.

• Periodical: International Journal of Engineering Research in Africa (Volume 37)
• Pages: 29-42
• DOI: https://doi.org/10.4028/www.scientific.net/JERA.37.29
• Online since: August 2018
• Authors: Abderrahmane Mokhtari*, Mohammed Belkheiri
• Keywords: Exponential Weighted Moving Average, Fault Diagnosis, Statistical Analysis, Support Vector Machine, Wind Turbine Benchmark Model
