Abstract: The present paper is focused on ceramic–metal composites obtained via different
technologies which leads to different microstructures in terms of size and distribution of metal phase. Composites analysed in paper were produced by the following methods:(a) infiltration of porous ceramics by metal, (b) consolidation under high pressure and (c) sintering of ceramic powder coated by metal. Their microstructures were investigated by scanning and transmission electron microscopy methods. The three methods of composite fabrication employed in the present study result in specific spatial distribution and dispersion of metal phase. Presureless infiltration of porous ceramics by liquid metal is driven by capillary force and make it possible to produce microstructure with percolation of metal phase in ceramic matrix. The volume fraction of metal phase in this case depends on the size
of pores. The size of pores influence also the kinetics and extent of infiltration. Ceramic preforms with small size of pore are not fully infiltrated. This method is useful for composite with size of metal phase in the range of micrometers. Hot pressing under high pressure produces microstructures of composites with metal phase grain size in the range from nano to micrometers. Moreover, it allows to achieve the nanometric size of ceramic grains. In the case of ceramic powders covered by metal, compression and hot pressing preserves nanometric size of metal. The grain growth of ceramic grains is suppressed.
Abstract: The investigation on joining of SiC to SiC has been conducted for some years. It is essential that the mechanical and thermal properties of the joints should meet the requirements of engineering. In view of the fact that the ternary carbide Ti3SiC2 has shown unique mechanical and thermal properties, it is promising to join SiC to SiC using ternary carbide Ti3SiC2 as filler (welding compound), and this is the subject to deal with in this paper. The joining of SiC to SiC has been successfully realized by hot pressing reaction joining process using Ti3SiC2 powder as filler. The
optimized technological parameters have been obtained by orthogonal experiments, under which the achieved weld strength is higher than that of the welding base material SiC ceramic. Ti3SiC2 is stable up to 1200oC in Ar atmosphere with an external pressure. At the joining temperatures of 1300～ 1600oC the main phases of the interface are Ti3SiC2, TiC and TiSi2. The mechanism of bonding at the interface is interdiffusion and chemical reaction.
Abstract: A model for designing sandwich nanocomposite ceramic tool materials with symmetrical distribution was presented. By adding nano-sized Al2O3 particles into the submicro-sized Al2O3 and TiCN, Al2O3/TiCN sandwich nanocomposite ceramic tool materials were fabricated by means of powder-laminating and hot-pressing technique. The experimental results showed that optimal mechanical properties were achieved for the composite with the addition of 35 vol.% TiCN particles in the middle layer and 45 vol.% TiCN particles in the outer layers, layer thickness ratio is 0.3, with the flexural strength reaching respectively 900MPa，fracture toughness and Vicker's hardness in the surface layers being 6.5MPa•m1/2 and 19.2GPa.
Authors: Xiang Zheng, Xiao Yan Tong, Hao Chen, Lei Jiang Yao
Abstract: An experimental study of low-velocity impact characteristics and strength after impact was carried out on both woven fiber-reinforced resin matrix composites and woven fiber-reinforced ceramic matrix composites. The test specimens were impacted using a dropped-weight impact test apparatus with an instrumented spherical tip. Ultrasonic C-scan was used in nondestructive testing to characterize and quantify the impact damage. Much more damage of ceramic matrix composites than that of resin matrix composites occur and process in loading stage. The peak load of resin matrix composites is higher than that of ceramic matrix composites. According to the results of observing optical photographs and C-scan images, the damage area of ceramic matrix composites is greater than that of resin matrix composites and the difference increases as the energy increases. Damage resistance of ceramic matrix composites is lower than that of resin matrix composites, but damage tolerance of ceramic matrix composites is higher than that of resin matrix composites.
