The Assessment of Influence of the Design Factors on the Reliability of BGA Solder Joints

Abstract:

In recent years, package downsizing has become one of biggest trends in packaging technologies because of miniaturization and the high integration of electronic devices. As a result, the reliability of fatigue life has been prioritized as an important concern, since the thermal expansion difference between a package and printed circuit board causes thermal fatigue. But, the reliability of thermal fatigue life may be lowered by the dispersion of design factors such as the dimensions, shapes, and material properties of package systems. Also, the fracture modes (fatigue fracture, brittle destruction in the interface, and compound destruction, and so on) will be affected by these dispersion factors. Although this dispersion should be reduced in order to improve the reliability, reducing all dispersion is inefficient and time-consuming. So, the factors that greatly contribute to thermal fatigue life have to be reduced. In this study, evaluations of the influence of various design factors on the reliability of soldered joints of a BGA (Ball Grid Array) were carried out, and got each influence. With the results, design engineers can rate each factor’s effect on reliability and assess the reliability of their design beginning at the concept design stage. Consequently, it will be possible to avoid almost all reliability problems from the beginning. Also, by rating the factors, the design period can be shortened

• Periodical: Key Engineering Materials (Volumes 297-300)
• Pages: 1822-1827
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.297-300.1822
• Online since: November 2005
• Authors: Jae Chul Jin, Qiang Yu, Tadahiro Shibutani, Hirokazu Abe, Masaki Shiratori
• Keywords: BGA Package, Reliability Assessment, Sensitivity Analysis

References

[1] Y. Uegai, S. Tani, A. Inoue and S . Yoshioka: ASME, Advances in Electronic Packaging, EEP Vol. 4-1 (1993), pp.493-498.

[2] H.D. Solomon: IEEE Trans. CHMT-9 (4) (1986), pp.423-432.

[3] Qiang Yu and Masaki Shiratori (Yokohama National University): Fatigue-Strength Prediction of Microelectronics Solder Joints Under Thermal Cyclic Loading, IEEE Trans. Vol. 20 No. 2 (1998), pp.266-273.

DOI: 10.1109/95.623020

[4] Qiang Yu, Do-Seop Kim, Tadahiro Shibutani and Masaki Shiratori: Nonlinear Behavior Sudy on Effect of Hardening Rule of Lead Free Solder Joint", Proceedings of Inter PACK, 03, IPACK 2003-35250.

DOI: 10.1115/ipack2003-35250

[5] S. Verma, A. Desgupta and D. Baker: A Numerical Study of Fatigue Life of J-Leaded Solder Joints Using the Energy Partitioning Approach, Transaction of the ASME Vol. 115 (1993), pp.416-423.

DOI: 10.1115/1.2909351

[6] T-Y. Pan: Critical Accumulated Strain Energy (CASE) Failure Criterion for Thermal Cycling Fatigue of Solder Joints, Journal of Electronic Packaging Vol. 116 (1994), p.165.

DOI: 10.1115/1.2905681

[7] P. Bhatti and K. Gschwend: Effect of Global CTE Mismatch on Solder Joint Creep in SMT Devices, ASME, Advances in Electronic Packaging, EEP Vol. 8 (1994), p.56.

[8] S.S. Manson: Interfaces Between Fatigue Creep and Fracture, Int. J. of Fracture Mechanics 2 (1) (1996), pp.327-363.

DOI: 10.1007/bf00698478
