Structural Assessment for Bogie Frame of 180km/h Korean Tilting Train

Abstract:

This paper has performed the fatigue strength evaluation for the bogie frame of Korean tilting train. In order to verify the structural safety of the bogie frame, we firstly investigated the loading condition imposed on the bogie frame. The bogie frame of the tilting train is exposed to the more severe loadings compared with the conventional one because of the tilting of the carbody and the high-speed curve negotiation. We have conducted some multi-body dynamic analyses to extract the load condition by tilting on curve. The finite element analysis is used to obtain the stress distribution. Through this study, we could make sure the safety of the tilting bogie frame.

• Periodical: Key Engineering Materials (Volumes 297-300)
• Pages: 345-350
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.297-300.345
• Online since: November 2005
• Authors: Jung Seok Kim, Nam Po Kim
• Keywords: Bogie, Curve, Fatigue Analysis, Multibody Dynamics (MBD), Tilting Bolster, Tilting Train

References

[1] J.T. Pearson, R.M. Goodall and I. Pratt: Proc Instn Mech Engrs. Vol. 212 Part F (1998), pp.43-60.

[2] J. Forstberg: Motion-Related Comfort in Tilting Trains VTI Rapport 449A (2000).

[3] S. Koyanagi, I. Okamoto, S. Fujimori and K. Terada: JSME International Journal Vol. 32 No. 2 (1989), pp.316-322.

[4] SwedeRail: High Speed Tilting EMUs for Conventional Railways to KRRI Final Report (2003).

[5] UIC Code 615-4: Motive Power Units Bogies and Running Gear Bogie Frame Structure Strength Tests (1994).
