Delamination Growth in Ball Grid Array Electronic Package

Abstract:

The delamination problem in plastic ball grid array electronic package was investigated analytically and experimentally. The ANSYS code was used in the analysis to find the deformation and the stress distribution in electronic package due to the thermal mismatch between different materials at reflow temperature with saturated moisture pressure at the delaminated region. The stress intensity factor and the strain energy release rate at the tip of interfacial delamination were calculated using the fracture mechanics approach. The results show that the delaminaton occurs at the corner of the die pad and at the middle region of the die attach/die pad interface. The delaminaton grew from the middle region of the die attach/die pad interface, along the epoxy molding compoend/die pad interface, the epoxy molding compound/substrate interface to the exterior surface. Possible growth directions of the interfacial delamination in plastic ball grid array electronic package were identified and observed in the experimental results. In addition, the reflow temperature affected the stress distribution and the strain energy release rate at the tip of interfacial delaminaton.

• Periodical: Key Engineering Materials (Volumes 306-308)
• Pages: 363-368
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.306-308.363
• Online since: March 2006
• Authors: Meng Kao Yeh, In Shung Lee
• Keywords: Ball Grid Array, Delamination, Electronic Package, Strain Energy Release Rate (SERR)

References

[1] S. Yi, J.S. Goh and J.C. Yang: IEEE Transactions on Components, Packaging, and Manufacturing Technology - Part B, Vol. 20, (1997), p.247.

[2] A.A.O. Tay, G.L. Tan and T.B. Lim: IEEE Transactions on Components, Packaging, and Manufacturing Technology - Part B, Vol. 17, (1994), p.201.

[3] M.K. Yeh and K.C. Chang: InterPACK'99, EEP-Vol. 26-1, Hawaii, June 13-18, (1999).

[4] Y.H. Mei, and S. Liu: Application of Fracture Mechanics in Electronic Packaging and Materials, ASME, EEP-Vol. 11/MD-Vol. 64, (1995).

[5] Y.T. Chiou and Y.C. Hu: Industrial Material, Vol. 141 (1998), p.145 (in Chinese).

[6] R. Darveaux, L. Norton and F. Carney: Electronic Components and Technology Conference, (1995), p.1057.

[7] A.J. Kinloch: Adhesion and Adhesives-Science and Technology (Chapman and Hill, New York 1987).

[8] Y.B. Park and J. Yu: IEEE/CPMT International Electronics Manufacturing Technology Symposium, (1997), p.12.

[9] C.A. Le Gall, J. Qu and D.L. McDowell: Electronic Components and Technology Conference, (1996), p.430.

[10] K.Y. Lee and T.S. Lee: Journal of Electronic Packaging, Vol. 121 (1999), p.148.

[11] S.H. Ahn and Y.S. Kwon: IEEE Transactions on Components, Packaging, and Manufacturing Technology - Part B, Vol. 18 (1995), p.491.

[12] J.H. Lau, and S.W.R. Le: Journal of Electronic Packaging, Vol. 122 (2000), p.34.

[13] ANSYS Theory Reference. 000855. Eigth Edition. SAS IP, Inc.

[14] T. Saitoh, H. Matsuyama and M. Toya: IEEE Transactions on Components, Packaging, and Manufacturing Technology - Part B, Vol. 21 (1998), p.422.

[15] A.A.O. Tay and K.Y. Goh: Electronic Components and Technology Conference, (1999), p.694.

[16] W.O. Soboyejo and V. Kenner: Materials Research Society Symposium Proceeding, Vol. 445 (1997), p.263.

[17] JESD22-A113-A, JEDEC Standard, (Electronic Industries Association, Arlington, VA, 1995).
