Material Tester Using a Controlled Oscillator and an Inertial Mass

Abstract:

In this paper, a controlled oscillation using the levitation mass method (LMM) for material with nonlinear viscoelasticity is proposed. Since LMM is a very accurate and efficient method of measuring a varying force, it has a possibility to apply to the material tester. For LMM, system identification process is introduced to grasp the nonlinear components of the restoring force. The process consists of the experiment and frequency analysis for higher modes which originate for the nonlinear restoring force. The input signal is then derived based on the identification results. By adding the proposed identification process to LMM, the arbitrary waveform of the force can be investigated even in the open-loop excitation. The effectiveness of the proposed oscillation method is verified through the LMM-based experiments.

• Periodical: Key Engineering Materials (Volumes 381-382)
• Pages: 457-460
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.381-382.457
• Online since: June 2008
• Authors: Seiji Hashimoto, Yusaku Fujii
• Keywords: Forced Oscillation, Measurement of Force, Measurement of Mass, Modeling, Viscoelasticity

References

[1] Y. Fujii: Rev. Sci. Instrum., Vol. 75 (2004), pp.119-123.

[2] Y. Fujii and T. Yamaguchi: , Journal of Materials Science, Vol. 40 (2005), pp.4785-4790.

[3] T. Yamaguchi, Y. Fujii, K. Nagai and S. Maruyama: Mechanical Systems and Signal Processing, Vol. 20 (2006), p.1905-(1922).

[4] Y. Fujii: Meas. Sci. Technol., Vol. 17 (2006), No. 7, p.1935-(1940).

[5] S. Hashimoto, K. Hara, H. Funato and K. Kamiyama: IEEE Trans. on Industry Applications, Vol. 37 (2001), No. 3, pp.806-811.

DOI: 10.1109/28.924762

[6] S. Hashimoto, K. Ohishi, T. Ohishi, T. Ishikawa, K. Kosaka, Y. Egashira, H. Kubota and T. Ohmi: Proc. of the 8th IEEE International Workshop on Advanced Motion Control (AMC'04), Vol. 1 (2004), pp.559-564.

DOI: 10.1109/amc.2004.1297929

[7] S. Hashimoto, Y. Fujii, M. Kigure and T. Ishikawa: Proc. of the 2nd IEEE Conference on Industrial Electronics and Applications (ICIEA2007), (2007).

[8] G. C. Goodwin, S. F. Graebe and M. E. Salgado: Control System Design (Prentice Hall, Upper Saddle River, New Jersey, 2001).

[9] L. Ljung: System Identification - Theory for the user (Prentice Hall, Englewood Cliffs, New Jersey, 1999).

[10] G. P. Liu: Nonlinear Identification and Control (Springer, London, 2001).

[11] P. P. Vaidyanathan: Multirate Systems And Filter Banks (Prentice Hall, New Jersey, 1993). 0. 3 0. 4 0. 5 0. 6 0. 7 -1. 5 -1. 0 -0. 5 0 0. 5 1. 0 1. 5 Time [s] Output Fmass [N] (a) Output signal Fmass with/without compensation 1 2 3 4 5 6 7 8 9 10 0 0. 2 0. 4 0. 6 0. 8 1. 0 Number of mode Gain ratio: mnth/m1st (b) Reduction of harmonic component Fig. 3 Experimental results for open loop-based forced oscillation method. : without compensation : with compensation.
