Blade Failure in Second Stage Turbine

Abstract:

The present paper reports the investigation of a sudden blade fracture leading to a fatal engine failure. The blade sample was subjected to a series of examinations, including visual examination and photographic documentation, optical microscopy, scanning electron microscopy (SEM), using both energy dispersive spectroscopy (EDS) and X-ray mapping. Analysis of all elements show that loss of aluminum from coating due to oxidation and coating phases changing; decreasing of alloy ductility and toughness due to carbides precipitation in grain boundaries; degradation of the alloy gamma prime γ' phase (aging and coarsening) and micro cavities. These were found on fracture surfaces which served as an origin of creeping failure mechanism and are the most important factor for failure of this blade.

• Periodical: Key Engineering Materials (Volumes 385-387)
• Pages: 393-396
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.385-387.393
• Online since: July 2008
• Authors: K. Mohammadi, Akbar K. Haghi
• Keywords: Blade, Corrosion, Creep, Fatigue

References

[1] Z. Mazur, Rafael Garcia-Illescas, Jorge Aguirre-Romano, Norberto Perez-Rodriguez, Steam turbine blade failure analysis, Engineering Failure Analysis 15 (2008) 129-141.

DOI: 10.1016/j.engfailanal.2006.11.018

[2] J. Safari, S. Nategh, On the heat treatment of Rene-80 nickel-base superalloy, Journal of Materials Processing Technology 176 (2006) 240-250.

DOI: 10.1016/j.jmatprotec.2006.03.165

[3] T. Carter, Common failures in gas turbine blades, Engineering Failure Analysis 12 (2005) 237- 247.

DOI: 10.1016/j.engfailanal.2004.07.004

[4] J.S. Houa, J.T. Guo, L.Z. Zhou, C. Yuan, H.Q. Ye, Microstructure and mechanical properties of cast Ni-base superalloy K44, Materials Science and Engineering A 374 (2004) 327-334.

DOI: 10.1016/j.msea.2004.03.005

[5] M. Marx, H. Vehoff, Propagation of microcracks in single crystalline nickel-based superalloys: size effects on the crack opening, Materials Science and Engineering A 387-389 (2004) 511-515.

DOI: 10.1016/j.msea.2003.12.092

[6] Z. Mazur, A. Luna-Ramı´rez, J.A. Jua´rez-Islas, A. Campos-Amezcua , Failure analysis of a gas turbine blade made of Inconel 738LC alloy, Engineering Failure Analysis 12 (2005) 474-486.

DOI: 10.1016/j.engfailanal.2004.10.002

[7] M.R. Khajavi, M.H. Shariat, Failure of first stage gas turbine blades, Engineering Failure Analysis 11 (2004) 589-597.

DOI: 10.1016/j.engfailanal.2003.08.010

[8] K. Mohammadi, A.K. Haghi, Journal of Material Processing Technology, In press, DOI: 10. 1016/j. jmatprotec. 2007. 11. 273.

[9] R. Viswanathan, An investigation of blade failure in combustion turbines, Engineering Failure Analysis 8(2001)493-511.

DOI: 10.1016/s1350-6307(00)00043-1
