Development of Automatic Measurement Platform for Servo Valve Nozzle Volume

Abstract:

This paper introduces an automatic measurement technology of electro-hydraulic servo valve nozzle volume. Since there are several disadvantages of manual measurement in workplace, develops a new kind of intelligent volume test platform which can adjust pressure and record data automatically under constant oil temperature and match through computer. The outcome of the nozzle match experiment in the end satisfies the operating requirements.
