Analysis of Retrofitted RC Beam with Fixed End Supports against Blast Loads

Abstract:

Currently, there are adequate guidelines available for FRP retrofitting RC structures against static and seismic loads. However, there is still limited information on retrofitting RC structures against short-duration dynamic loading effects such as blast loading. Due to the increasing threat of terrorism in recent years, retrofitting of RC structures against blast loading is of paramount importance in structural engineering. In this paper, a dynamic model that is based on single-degree-of-freedom (SDOF) approach is developed for the analysis of the response of retrofitted fixed end supported RC slabs subjected to blast loads. A previously validated layered capacity analysis method is used to determine the yielded and ultimate blast resistant capacity of a cross-section of a RC slab which allows varying strain rates with time along the depth of the member. The corresponding deflections are determined by plastic hinge analysis. To simplify the calculation process, a tri-linear resistance-deflection function which consists of elastic, elasto-plastic and plastic region for fixed end supported RC slabs is converted to an equivalent bilinear function. This developed model can adequately predict the retrofitted members’ response to blast loading. It is then is used to conduct a parametric study to optimise the retrofitting of RC slabs subjected to blast loading by varying the quantity, material type and technique of retrofitting.

• Periodical: Key Engineering Materials (Volumes 400-402)
• Pages: 795-800
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.400-402.795
• Online since: October 2008
• Authors: Chengqing Wu, C. Wu, William Chen, Deric John Oehlers
• Keywords: Blast Load, FRP Retrofitting, Reinforced Concrete (RC) Beam, Retrofit Techniques

References

[1] TM5-1300: Structures to resist the effect of accidental explosions (US Department of the Army, Navy and Air Force Technical Manual, 1990).

[2] American Society of Civil Engineers (ASCE). Design of blast resistant buildings in petrochemical facilities, ASCE, 1997, USA.

[3] I. Day, C. Glynn, M. Merrigan, A. Spencer: Retrofitting reinforced concrete members against blast loading using near surface mounted FRP in Final Year Research Project Report, School of Civil and Environmental Engineering, the University of Adelaide, Australia, (2006).

[4] L.J. Malvar, J.E. Crawford: Dynamic increase factors for steel reinforcing bars (Twenty-Eighth DDESB Seminar, Orlando, USA, 1998).

[5] J. M. Biggs: Introduction to Structural Dynamics (McGraw-Hill Book Company, New York, USA, 1964).
